240/600 ECAK30/W33 Double Row Spherical Roller Bearing

240/600 ECAK30/W33 Double Row Spherical Roller Bearing

The 240/600 ECAK30/W33 is a double-row spherical roller bearing with a large 600mm bore and 870mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 1,928,861 lbf and operates smoothly at speeds up to 560 RPM.

Its brass cage and open design ensure durability, while the tapered bore (1:30) provides secure fitting. The bearing includes lubrication grooves and holes for easy maintenance.

Suitable for heavy-duty applications like industrial machinery or large gearboxes, it performs well in temperatures from -30°C to 200°C. Compliant with RoHS and REACH standards.

Weighing 535kg, this robust bearing is interchangeable with SKF models, making it a reliable choice for replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 240/600 ECAK30/W33
  • Brand TFL
  • Interchangeable SKF
  • Size 600 x 870 x 272 mm
  • Bore Dia 600 mm
  • Bore Dia Tolerance +0.05mm to 0
  • Outer Dia 870 mm
  • Outer Dia Tolerance -0.1mm to 0
  • Width 272 mm
  • Width Tolerance -0.5mm to 0
  • Shoulder Dia Of Inner Ring 675 mm
  • Shoulder/Recess Dia Of Outer Ring 774 mm
  • Width Of Lubrication Groove 22.3 mm
  • Diameter Of Lubrication Hole 12 mm
  • Chamfer Dimension min.6 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:30
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 1928861 lbf
  • Static Radial Load 3821752 lbf
  • Max Speed 560 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 535 kg

Features

Performance Features of 240/600 ECAK30/W33 Bearing

240/600 ECAK30/W33 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 1,928,861 lbf, making it suitable for heavy-duty industrial applications.

The brass cage ensures proper roller alignment, reducing friction and enhancing durability.
With a maximum speed of 560 rpm, it delivers reliable performance under demanding conditions.

240/600 ECAK30/W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its tapered bore design simplifies installation, ensuring a secure fit and reducing maintenance needs.

The lubrication groove and hole design in 240/600 ECAK30/W33 Bearing promote consistent oil distribution.
This feature extends service life and maintains smooth operation even in high-load scenarios.

Application

Industrial Uses of 240/600 ECAK30/W33 Bearing
The 240/600 ECAK30/W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. Its brass cage ensures smooth operation even under demanding conditions.

Where Is 240/600 ECAK30/W33 Bearing Used?
You’ll often find 240/600 ECAK30/W33 Bearing in mining equipment, where its robust construction withstands harsh environments. The tapered bore design also makes it easy to install and maintain in large-scale applications.

Built for Heavy-Duty Use: 240/600 ECAK30/W33 Bearing
240/600 ECAK30/W33 Bearing excels in wind turbines, supporting the main shaft with its high load capacity. The lubrication groove and hole design help extend service life in continuous operation.

Automotive vs Aerospace: Applications of 240/600 ECAK30/W33 Bearing
While 240/600 ECAK30/W33 Bearing isn’t typical in cars, it’s vital in aerospace landing gear systems. Its chrome steel rollers and brass cage provide reliability under extreme stress and temperature variations.

Key Fields for 240/600 ECAK30/W33 Bearing
In paper mills, 240/600 ECAK30/W33 Bearing ensures smooth operation of large rollers. The spherical roller design compensates for misalignment, reducing wear and downtime.
