23988 CAC/C083W513 Double Row Spherical Roller Bearing

23988 CAC/C083W513 Double Row Spherical Roller Bearing

The 23988 CAC/C083W513 is a double-row spherical roller bearing with a 440mm bore and 600mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 563371 lbf and operates smoothly at speeds up to 1000 RPM.

Its brass cage ensures durability, while the open design allows for easy lubrication. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

With a C3 radial clearance, it accommodates slight misalignments, making it suitable for heavy-duty applications. Ideal for use in industrial machinery like crushers or large gearboxes where high radial loads are present.

Weighing 98kg, it’s built for strength and longevity. Compliant with RoHS and REACH standards, it’s a dependable choice for replacements, interchangeable with SKF bearings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23988 CAC/C083W513
  • Brand TFL
  • Interchangeable SKF
  • Size 440 x 600 x 118 mm
  • Bore Dia 440 mm
  • Bore Dia Tolerance -0.045mm to 0
  • Outer Dia 600 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 118 mm
  • Width Tolerance -0.45mm to 0
  • Shoulder Dia Of Inner Ring 484 mm
  • Shoulder/Recess Dia Of Outer Ring 553 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 563371 lbf
  • Static Radial Load 1101564 lbf
  • Max Speed 1000 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 98 kg
  • Price （US$） US$4,666.32

Features

Core Advantages of 23988 CAC/C083W513 Bearing

23988 CAC/C083W513 Bearing features a double-row spherical roller design, ideal for handling combined radial and thrust loads.
Its chrome steel construction ensures durability, while the brass cage provides stability under heavy loads.

With a dynamic radial load capacity of 563,371 lbf, it performs reliably in demanding industrial applications.
The bearing operates smoothly at speeds up to 1,000 rpm, balancing efficiency and strength.

Designed for a wide temperature range of -30° to 200°C, it suits various working environments.
Its C3 radial clearance allows for thermal expansion, ensuring consistent performance.

The lubrication groove and hole design simplifies maintenance, extending service life.
Weighing 98 kg, it is built for heavy-duty machinery requiring robust support.

Application

Industrial Uses of 23988 CAC/C083W513 Bearing
23988 CAC/C083W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads. The brass cage ensures smooth operation even under high stress.

In automotive applications, 23988 CAC/C083W513 Bearing supports large drivetrain components, such as truck axles, thanks to its robust construction and high load capacity. Its C3 radial clearance allows for thermal expansion in demanding conditions.

For industrial fans and blowers, 23988 CAC/C083W513 Bearing’s chrome steel rollers provide durability in high-speed environments. The open design simplifies lubrication, extending service life in continuous operations.

Key Fields for 23988 CAC/C083W513 Bearing
23988 CAC/C083W513 Bearing excels in mining equipment, where its combined load capacity and resistance to harsh conditions are essential. The large bore size accommodates heavy shafts commonly found in this sector.

In power generation, 23988 CAC/C083W513 Bearing is often found in turbines and generators, handling high radial loads with reliability. Its P5 radial run-out ensures precision in critical applications.

Built for Heavy-Duty Use: 23988 CAC/C083W513 Bearing
23988 CAC/C083W513 Bearing is ideal for construction machinery like cranes and excavators, where its spherical rollers adapt to dynamic loads. The wide temperature range suits both indoor and outdoor use.

For paper manufacturing equipment, 23988 CAC/C083W513 Bearing’s brass cage reduces friction in high-moisture environments. Its large lubrication groove ensures consistent performance in continuous production lines.
