23956 CC/W513 Double Row Spherical Roller Bearing

23956 CC/W513 Double Row Spherical Roller Bearing

The 23956 CC/W513 is a double-row spherical roller bearing with a 280mm bore and 380mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 228406 lbf and operates smoothly at speeds up to 1700 RPM.

Its open design allows for easy lubrication, with a 6mm hole and 11.1mm groove for efficient maintenance. The steel cage ensures durability, while the spherical rollers accommodate slight misalignments.

Suitable for heavy-duty applications like industrial gearboxes or mining equipment, it performs well in temperatures from -30°C to 200°C. Weighing 24kg, it’s built for stability under high radial loads.

Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF bearings. Ideal for machinery requiring long-lasting performance and easy maintenance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23956 CC/W513
  • Brand TFL
  • Interchangeable SKF
  • Size 280 x 380 x 75 mm
  • Bore Dia 280 mm
  • Bore Dia Tolerance -0.035mm to 0
  • Outer Dia 380 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 75 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 308 mm
  • Shoulder/Recess Dia Of Outer Ring 352 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 228406 lbf
  • Static Radial Load 395664 lbf
  • Max Speed 1700 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 24 kg

Features

How Is 23956 CC/W513 Bearing Engineered for Reliability?

23956 CC/W513 Bearing features a double-row spherical roller design, ideal for handling combined radial and thrust loads.

Its chrome steel construction ensures durability, with a dynamic radial load capacity of 228406 lbf for demanding applications.

The steel cage maintains roller alignment, reducing friction and extending operational life.

With a maximum speed of 1700 rpm and a temperature range of -30° to 200°C, it performs reliably in varied conditions.

Application

Industrial Uses of 23956 CC/W513 Bearing
The 23956 CC/W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles combined loads effectively. Its chrome steel construction ensures durability in harsh industrial environments.

Where Is 23956 CC/W513 Bearing Used?
You’ll often find 23956 CC/W513 Bearing in mining equipment, where its high dynamic radial load capacity supports heavy-duty operations. The open seal design simplifies lubrication, making maintenance straightforward.

Built for Heavy-Duty Use: 23956 CC/W513 Bearing
23956 CC/W513 Bearing excels in applications like paper mills and wind turbines, thanks to its robust steel cage and spherical roller design. Its wide temperature range (-30° to 200°C) makes it versatile for extreme conditions.

Automotive vs Aerospace: Applications of 23956 CC/W513 Bearing
In automotive systems, 23956 CC/W513 Bearing supports large drivetrain components, while in aerospace, its precision handles high-speed rotor assemblies. The metric sizing ensures compatibility across global standards.

Essential Roles of 23956 CC/W513 Bearing
23956 CC/W513 Bearing is vital in construction equipment like cranes, where its static radial load capacity ensures stability. The cylindrical bore design simplifies installation on shafts.
