23940 CC/W507 Double Row Spherical Roller Bearing

23940 CC/W507 Double Row Spherical Roller Bearing

The 23940 CC/W507 is a double-row spherical roller bearing with a 200mm bore and 280mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 146351 lbf and operates smoothly at speeds up to 2400 RPM.

Its open design allows for easy lubrication, with an 8.3mm groove and 4.5mm holes for efficient maintenance. The steel cage ensures durability, while the spherical rollers accommodate slight misalignments.

This bearing works well in temperatures from -30°C to 200°C, making it suitable for harsh environments. It’s interchangeable with SKF bearings, ideal for heavy machinery like crushers or conveyor systems.

Weighing 11.5kg, it’s built for robust performance. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23940 CC/W507
  • Brand TFL
  • Interchangeable SKF
  • Size 200 x 280 x 60 mm
  • Bore Dia 200 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 60 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 222 mm
  • Shoulder/Recess Dia Of Outer Ring 258 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 146351 lbf
  • Static Radial Load 233801 lbf
  • Max Speed 2400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 11.5 kg
  • Price （US$） US$649.13

Features

Performance Features of 23940 CC/W507 Bearing

23940 CC/W507 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 146351 lbf, ensuring dependable performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 2400 rpm, it maintains efficiency under demanding conditions.

23940 CC/W507 Bearing operates in temperatures from -30° to 200°C, suitable for varied environments.
The steel cage ensures roller alignment, enhancing durability and reducing maintenance needs.

Lubrication grooves and holes in 23940 CC/W507 Bearing facilitate smooth operation and extended service life.
Its standard radial clearance (CN) ensures consistent performance across different applications.

Application

Industrial Uses of 23940 CC/W507 Bearing
The 23940 CC/W507 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. Its chrome steel construction ensures durability in demanding environments.

Where Is 23940 CC/W507 Bearing Used?
You’ll often find 23940 CC/W507 Bearing in mining equipment, where its high load capacity and spherical roller design accommodate misalignment. The open seal type allows for easy lubrication, extending service life.

Built for Heavy-Duty Use: 23940 CC/W507 Bearing
23940 CC/W507 Bearing excels in paper mill machinery, supporting large rollers under constant stress. Its wide temperature range (-30° to 200°C) makes it suitable for both hot and cold processing lines.

Automotive vs Aerospace: Applications of 23940 CC/W507 Bearing
In automotive applications, 23940 CC/W507 Bearing supports large drivetrain components, while in aerospace, it’s used in ground support equipment. The metric sizing ensures compatibility with global standards.

Essential Roles of 23940 CC/W507 Bearing
23940 CC/W507 Bearing is vital in wind turbine gearboxes, where its high dynamic load rating (146351 lbf) handles variable forces. The steel cage provides stability during high-speed rotation (up to 2400 rpm).
