23940 CC/C3HW33 Double Row Spherical Roller Bearing

23940 CC/C3HW33 Double Row Spherical Roller Bearing

The 23940 CC/C3HW33 is a double-row spherical roller bearing with a 200mm bore and 280mm outer diameter, crafted from robust chrome steel. It manages combined loads up to 146351 lbf and operates smoothly at speeds up to 2400 RPM.

Its open design and C3 radial clearance allow for easy lubrication, while the steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where combined loads are common.

Weighing 11.5kg, it’s built to handle demanding conditions while complying with RoHS and REACH standards for safety.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23940 CC/C3HW33
  • Brand TFL
  • Interchangeable SKF
  • Size 200 x 280 x 60 mm
  • Bore Dia 200 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 60 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 222 mm
  • Shoulder/Recess Dia Of Outer Ring 258 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 146351 lbf
  • Static Radial Load 233801 lbf
  • Max Speed 2400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 11.5 kg

Features

How Does 23940 CC/C3HW33 Bearing Handle Heavy Loads?

23940 CC/C3HW33 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 146351 lbf, ensuring dependable performance in heavy-duty applications.
The steel cage maintains roller alignment, reducing friction and enhancing durability.
With a maximum speed of 2400 rpm, it delivers both strength and efficiency.

What Makes 23940 CC/C3HW33 Bearing Suitable for High-Temperature Applications?

23940 CC/C3HW33 Bearing operates effectively in temperatures ranging from -30° to 200°C.
Its chrome steel construction ensures stability and performance even under extreme heat.
The open design allows for easy lubrication, maintaining smooth operation in demanding conditions.
This makes it ideal for industrial applications where temperature fluctuations are common.

Engineered for Precision: 23940 CC/C3HW33 Bearing

23940 CC/C3HW33 Bearing features a double-row spherical roller design for precise load distribution.
The cylindrical bore ensures a secure fit, reducing vibration and improving accuracy.
Its C3 radial clearance allows for thermal expansion, maintaining performance under varying conditions.
This precision engineering makes it suitable for high-performance machinery.

Radial vs Thrust Bearings: The Edge of 23940 CC/C3HW33 Bearing

23940 CC/C3HW33 Bearing excels in handling combined radial and thrust loads.
Its spherical roller design adapts to misalignment, ensuring smooth operation.
The high static radial load capacity of 233801 lbf provides reliability in demanding setups.
This versatility makes it a preferred choice for complex load applications.

Performance Features of 23940 CC/C3HW33 Bearing

23940 CC/C3HW33 Bearing includes a lubrication groove and holes for consistent grease distribution.
The 8.3 mm groove width and 4.5 mm hole diameter ensure optimal lubrication flow.
This design reduces wear and extends the bearing’s service life.
It’s a practical solution for applications requiring regular maintenance.

Application

Industrial Uses of 23940 CC/C3HW33 Bearing
23940 CC/C3HW33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction also compensates for misalignment, ensuring smoother operation in demanding conditions.

Where Is 23940 CC/C3HW33 Bearing Used?
You’ll often find 23940 CC/C3HW33 Bearing in mining equipment, where its high dynamic load capacity and durability are essential for long-term performance. The C3 radial clearance also helps accommodate thermal expansion in high-temperature environments.

Built for Heavy-Duty Use: 23940 CC/C3HW33 Bearing
23940 CC/C3HW33 Bearing excels in paper mill machinery, thanks to its robust chrome steel construction and steel cage. The lubrication groove design ensures consistent performance even under continuous operation.

Automotive vs Aerospace: Applications of 23940 CC/C3HW33 Bearing
In automotive applications, 23940 CC/C3HW33 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring high load capacity. Its metric sizing makes it versatile across industries.

Perfect Fit for Automation: 23940 CC/C3HW33 Bearing
23940 CC/C3HW33 Bearing is ideal for robotic arms in manufacturing, where its spherical rollers reduce friction and improve precision. The open seal design allows for easy maintenance in automated systems.
