23252 CCK/C084W33 Double Row Spherical Roller Bearing

23252 CCK/C084W33 Double Row Spherical Roller Bearing

The 23252 CCK/C084W33 is a double-row spherical roller bearing with a 260mm bore and 480mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 763226 lbf and operates smoothly at speeds up to 1200 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The bearing requires lubrication and works in temperatures from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like mining equipment or industrial gearboxes where high radial loads are common.

Weighing 140kg, it’s a robust unit designed for long-lasting performance. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23252 CCK/C084W33
  • Brand TFL
  • Interchangeable SKF
  • Size 260 x 480 x 174 mm
  • Bore Dia 260 mm
  • Bore Dia Tolerance +0.052mm to 0
  • Outer Dia 480 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 174 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 329 mm
  • Shoulder/Recess Dia Of Outer Ring 408 mm
  • Width Of Lubrication Groove 22.3 mm
  • Diameter Of Lubrication Hole 12 mm
  • Chamfer Dimension min.5 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 763226 lbf
  • Static Radial Load 1067842 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C4
  • RoHs Compliant
  • REACH Compliant
  • Weight 140 kg
  • Price （US$） US$1,323.20

Features

Performance Features of 23252 CCK/C084W33 Bearing

23252 CCK/C084W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 763226 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 1200 rpm, it delivers reliable performance in various industrial settings.

23252 CCK/C084W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
The tapered bore design simplifies installation and enhances stability during operation.

The steel cage maintains roller alignment, reducing friction and extending bearing life.
Its C4 radial clearance allows for thermal expansion, ensuring consistent performance under varying conditions.

Application

Industrial Uses of 23252 CCK/C084W33 Bearing
The 23252 CCK/C084W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles combined loads effortlessly.
Its tapered bore ensures a secure fit, reducing slippage in high-vibration environments.

Where Is 23252 CCK/C084W33 Bearing Used?
You’ll often find 23252 CCK/C084W33 Bearing in mining equipment, where its high dynamic radial load capacity keeps operations running smoothly.
The open design allows for easy lubrication, extending its lifespan in dusty conditions.

Built for Heavy-Duty Use: 23252 CCK/C084W33 Bearing
23252 CCK/C084W33 Bearing excels in paper mills, supporting large rollers that require consistent performance under heavy loads.
The chrome steel construction ensures durability even in high-temperature environments.

Automotive vs Aerospace: Applications of 23252 CCK/C084W33 Bearing
In automotive applications, 23252 CCK/C084W33 Bearing is used in large trucks for axle support, thanks to its robust design.
In aerospace, it’s less common but can be found in ground support equipment where reliability is key.

Key Fields for 23252 CCK/C084W33 Bearing
Wind turbines benefit from 23252 CCK/C084W33 Bearing’s ability to handle misalignment and heavy radial loads.
The C4 radial clearance ensures smooth operation even under fluctuating temperatures.
