23236 CC/C3W502 Double Row Spherical Roller Bearing

23236 CC/C3W502 Double Row Spherical Roller Bearing

The 23236 CC/C3W502 is a double-row spherical roller bearing with a 180mm bore and 320mm outer diameter, built from tough chrome steel. It handles combined loads up to 350028 lbf and runs smoothly at speeds up to 1900 RPM.

Its spherical roller design allows slight misalignment, while the steel cage ensures durability under heavy loads. The open construction requires regular lubrication, with grooves and holes for easy maintenance.

This bearing suits high-temperature environments, working from -30°C to 200°C. With C3 radial clearance, it accommodates thermal expansion in demanding applications.

Ideal for industrial machinery like crushers or gearboxes, where heavy radial and axial loads are common. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF models.

Weighing 38.5kg, it’s built for robust performance in tough conditions. The cylindrical bore ensures a secure fit on shafts.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23236 CC/C3W502
  • Brand TFL
  • Interchangeable SKF
  • Size 180 x 320 x 112 mm
  • Bore Dia 180 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 320 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 112 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 211 mm
  • Shoulder/Recess Dia Of Outer Ring 271 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 350028 lbf
  • Static Radial Load 476595 lbf
  • Max Speed 1900 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 38.5 kg

Features

Performance Features of 23236 CC/C3W502 Bearing

23236 CC/C3W502 Bearing is built with double-row spherical rollers, handling combined loads efficiently.
Its chrome steel construction ensures durability, even under high dynamic radial loads of 350028 lbf.

The C3 radial clearance allows for thermal expansion, making it suitable for varied operating conditions.
With a maximum speed of 1900 rpm, it balances performance and reliability in heavy-duty applications.

23236 CC/C3W502 Bearing operates in temperatures from -30° to 200°C, adapting to extreme environments.
The steel cage maintains roller alignment, reducing friction and extending the bearing’s service life.

Application

Industrial Uses of 23236 CC/C3W502 Bearing
23236 CC/C3W502 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads with ease. The spherical roller type accommodates misalignment, making it reliable in rugged environments.

What Makes 23236 CC/C3W502 Bearing a Preferred Choice?
In mining equipment, 23236 CC/C3W502 Bearing’s high dynamic radial load capacity ensures longevity under extreme conditions. Its C3 clearance allows for thermal expansion, ideal for high-temperature operations.

Perfect Fit for Automation: 23236 CC/C3W502 Bearing
For conveyor systems in automated factories, 23236 CC/C3W502 Bearing offers smooth rotation and minimal maintenance. The steel cage and chrome steel rollers provide durability for continuous operation.

Automotive vs Aerospace: Applications of 23236 CC/C3W502 Bearing
In large trucks, 23236 CC/C3W502 Bearing supports axles and transmissions, while in aerospace, its precision handles loads in landing gear systems. The metric sizing ensures compatibility across industries.

Essential Roles of 23236 CC/C3W502 Bearing
23236 CC/C3W502 Bearing is vital in wind turbines, where its spherical rollers manage variable loads and misalignment. The open design simplifies lubrication, extending service life in remote installations.
