23226 CCK W33 C3 Double Row Spherical Roller Bearing

23226 CCK W33 C3 Double Row Spherical Roller Bearing

The 23226 CCK W33 C3 is a double-row spherical roller bearing with a 130mm bore and 230mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 185692 lbf and runs smoothly at speeds up to 2600 RPM.

Its open design and lubrication groove make maintenance straightforward, while the steel cage ensures durability. The bearing operates well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 14kg, it’s built to handle tough conditions while maintaining performance. Compliant with RoHS and REACH standards for safe industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23226 CCK W33 C3
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 230 x 80 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance +0.04mm to 0
  • Outer Dia 230 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 80 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 151 mm
  • Shoulder/Recess Dia Of Outer Ring 196 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 185692 lbf
  • Static Radial Load 238297 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 14 kg
  • Price （US$） US$247.14

Features

Performance Features of 23226 CCK W33 C3 Bearing

23226 CCK W33 C3 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 185692 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2600 rpm, it delivers reliable performance in various industrial settings.

23226 CCK W33 C3 Bearing features a steel cage that maintains roller alignment, reducing wear.
The C3 radial clearance allows for thermal expansion, ensuring stability in high-temperature environments.

Lubrication grooves and holes in 23226 CCK W33 C3 Bearing facilitate easy maintenance.
It operates efficiently in temperatures ranging from -30° to 200°C, adapting to diverse working conditions.

Application

Industrial Uses of 23226 CCK W33 C3 Bearing
The 23226 CCK W33 C3 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. Its spherical rollers help compensate for misalignment, ensuring smooth operation in demanding environments.

Where Is 23226 CCK W33 C3 Bearing Used?
You’ll often find the 23226 CCK W33 C3 Bearing in mining equipment, where its robust construction withstands harsh conditions. The tapered bore design also makes it easy to mount on shafts, reducing downtime during maintenance.

Built for Heavy-Duty Use: 23226 CCK W33 C3 Bearing
In paper mills, the 23226 CCK W33 C3 Bearing supports large rollers, thanks to its high dynamic load capacity. The steel cage and chrome steel rollers ensure long service life even under continuous operation.

Automotive vs Aerospace: Applications of 23226 CCK W33 C3 Bearing
While the 23226 CCK W33 C3 Bearing isn’t typically used in aerospace, it’s ideal for heavy vehicles like trucks and buses. Its ability to handle combined loads makes it suitable for gearboxes and differential systems.

Perfect Fit for Automation: 23226 CCK W33 C3 Bearing
In automated production lines, the 23226 CCK W33 C3 Bearing ensures reliable performance in conveyor systems. The C3 radial clearance allows for thermal expansion, preventing premature wear in high-speed applications.
