23152 CACK/C08W507 Double Row Spherical Roller Bearing

23152 CACK/C08W507 Double Row Spherical Roller Bearing

The 23152 CACK/C08W507 is a double-row spherical roller bearing with a 260mm bore and 440mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 577309 lbf and runs smoothly at speeds up to 1400 RPM.

Its brass cage and open design ensure durability and easy lubrication, with a temperature range of -30°C to 200°C. The tapered bore (1:12) provides a secure fit, while the spherical rollers accommodate misalignment.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 91kg, it’s a robust unit designed for long service life. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23152 CACK/C08W507
  • Brand TFL
  • Interchangeable SKF
  • Size 260 x 440 x 144 mm
  • Bore Dia 260 mm
  • Bore Dia Tolerance +0.052mm to 0
  • Outer Dia 440 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 144 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 314 mm
  • Shoulder/Recess Dia Of Outer Ring 380 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 577309 lbf
  • Static Radial Load 843034 lbf
  • Max Speed 1400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 91 kg
  • Price （US$） US$1,813.99

Features

Performance Features of 23152 CACK/C08W507 Bearing

23152 CACK/C08W507 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 577309 lbf, making it suitable for heavy-duty industrial applications.

The brass cage ensures smooth roller movement, reducing friction and extending operational life.
With a maximum speed of 1400 rpm, it maintains performance under demanding conditions.

23152 CACK/C08W507 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its tapered bore design simplifies installation, ensuring secure fitting and alignment.

The double-row spherical roller construction accommodates misalignment while maintaining load capacity.
Regular lubrication is required to keep 23152 CACK/C08W507 Bearing running smoothly over time.

Application

Industrial Uses of 23152 CACK/C08W507 Bearing
23152 CACK/C08W507 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The brass cage ensures smooth operation even under high stress.

In wind turbines, 23152 CACK/C08W507 Bearing supports the main shaft, thanks to its high dynamic load capacity and tolerance for misalignment. Its tapered bore design simplifies installation and maintenance in remote locations.

For mining equipment, 23152 CACK/C08W507 Bearing’s robust construction withstands harsh conditions, while the chrome steel rollers provide long-lasting performance. The lubrication groove design helps extend service intervals in dusty environments.

Where Is 23152 CACK/C08W507 Bearing Used?
You’ll find 23152 CACK/C08W507 Bearing in paper mills, where its spherical rollers compensate for shaft misalignment during high-speed operation. The metric sizing ensures compatibility with European industrial standards.

Built for Heavy-Duty Use: 23152 CACK/C08W507 Bearing
23152 CACK/C08W507 Bearing is ideal for steel plants, where its high-temperature tolerance and load capacity keep rolling mills running smoothly. The open design allows for easy lubrication in demanding conditions.

Automotive vs Aerospace: Applications of 23152 CACK/C08W507 Bearing
In large trucks, 23152 CACK/C08W507 Bearing supports drivetrain components, while in aerospace, its precision makes it suitable for ground support equipment. The P5 radial run-out ensures reliable performance in both sectors.
