23128 CC/C3W64E Double Row Spherical Roller Bearing

23128 CC/C3W64E Double Row Spherical Roller Bearing

The 23128 CC/C3W64E is a double-row spherical roller bearing with a 140mm bore and 225mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 148149 lbf and operates smoothly at speeds up to 2800 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing performs well in temperatures ranging from -30°C to 200°C, making it suitable for demanding environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 10.5kg, it’s built to last with a C3 radial clearance for optimal performance. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23128 CC/C3W64E
  • Brand TFL
  • Interchangeable SKF
  • Size 140 x 225 x 68 mm
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 225 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 68 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 159 mm
  • Shoulder/Recess Dia Of Outer Ring 197 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 148149 lbf
  • Static Radial Load 202328 lbf
  • Max Speed 2800 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 10.5 kg
  • Price （US$） US$327.47

Features

Performance Features of 23128 CC/C3W64E Bearing

23128 CC/C3W64E Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 148149 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2800 rpm, it delivers reliable performance in various industrial settings.

23128 CC/C3W64E Bearing operates in temperatures from -30° to 200°C, adapting to extreme environments.
The C3 radial clearance allows for thermal expansion, ensuring consistent performance under varying conditions.

Steel cage construction maintains roller alignment, reducing wear and extending the bearing’s service life.
Lubrication grooves and holes facilitate easy maintenance, keeping operational costs low.

Application

Industrial Uses of 23128 CC/C3W64E Bearing
23128 CC/C3W64E Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction helps accommodate misalignment, making it reliable in rugged environments.

Where Is 23128 CC/C3W64E Bearing Used?
In mining equipment, 23128 CC/C3W64E Bearing supports high-load applications such as conveyor pulleys and gearboxes. Its chrome steel rollers and C3 clearance ensure durability even under extreme operating conditions.

Built for Heavy-Duty Use: 23128 CC/C3W64E Bearing
23128 CC/C3W64E Bearing excels in steel mills, where it withstands high temperatures and heavy loads. The steel cage and lubrication groove design enhance performance in continuous operation.

Automotive vs Aerospace: Applications of 23128 CC/C3W64E Bearing
In large vehicles like trucks and buses, 23128 CC/C3W64E Bearing is used in wheel hubs and transmissions. Its robust construction ensures long service life, even under constant stress.

Key Fields for 23128 CC/C3W64E Bearing
23128 CC/C3W64E Bearing is ideal for wind turbines, where its ability to handle misalignment and heavy loads is crucial. The high dynamic load capacity makes it suitable for renewable energy applications.
