23126 CC/C3W64 Double Row Spherical Roller Bearing

23126 CC/C3W64 Double Row Spherical Roller Bearing

The 23126 CC/C3W64 is a double-row spherical roller bearing with a 130mm bore and 210mm outer diameter, built from sturdy chrome steel for long-lasting performance. It handles combined loads up to 131738 lbf and operates smoothly at speeds up to 3200 RPM.

Its open design and C3 radial clearance allow for easy lubrication, while the steel cage ensures durability under heavy loads. The bearing works reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery like gearboxes or conveyors where high radial loads are common.

Weighing 8.5kg, it’s a robust solution for demanding applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23126 CC/C3W64
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 210 x 64 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 210 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 64 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 148 mm
  • Shoulder/Recess Dia Of Outer Ring 184 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 131738 lbf
  • Static Radial Load 175351 lbf
  • Max Speed 3200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 8.5 kg

Features

Performance Features of 23126 CC/C3W64 Bearing

23126 CC/C3W64 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 131738 lbf, ensuring robust performance in heavy-duty applications.
The double-row spherical design accommodates misalignment, enhancing operational reliability.

How Is 23126 CC/C3W64 Bearing Engineered for Reliability?

23126 CC/C3W64 Bearing features a steel cage that maintains roller alignment, reducing friction and wear.
With a maximum speed of 3200 rpm, it delivers consistent performance under demanding conditions.
The C3 radial clearance allows for thermal expansion, making it suitable for high-temperature environments.

Built for Durability: 23126 CC/C3W64 Bearing

23126 CC/C3W64 Bearing’s lubrication groove and holes ensure efficient oil distribution, extending service life.
Its spherical roller design compensates for shaft misalignment, reducing stress on components.
The bearing operates in temperatures from -30° to 200°C, maintaining reliability in varied conditions.

Steel vs Ceramic Bearings: Strengths of 23126 CC/C3W64 Bearing

23126 CC/C3W64 Bearing’s chrome steel construction provides excellent strength and wear resistance.
The open design simplifies lubrication, ensuring smooth operation and reduced maintenance.
With a static radial load of 175351 lbf, it handles heavy loads with ease.

Application

Industrial Uses of 23126 CC/C3W64 Bearing
23126 CC/C3W64 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads effortlessly. The spherical roller construction ensures smooth operation even with slight misalignments.

Where Is 23126 CC/C3W64 Bearing Used?
You’ll often find 23126 CC/C3W64 Bearing in mining equipment, where its high dynamic load capacity and durability are essential. The C3 radial clearance also helps accommodate thermal expansion in demanding environments.

Built for Heavy-Duty Use: 23126 CC/C3W64 Bearing
23126 CC/C3W64 Bearing excels in paper mills and steel plants, thanks to its chrome steel rollers and robust steel cage. Its lubrication groove design ensures consistent performance even under continuous operation.

Automotive vs Aerospace: Applications of 23126 CC/C3W64 Bearing
In automotive applications, 23126 CC/C3W64 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring high reliability. The wide temperature range makes it versatile for both industries.

Perfect Fit for Automation: 23126 CC/C3W64 Bearing
23126 CC/C3W64 Bearing is ideal for robotic arms and conveyor systems in automated factories. Its combined load capacity and high-speed tolerance ensure precise movement and long service life.
