23122CCKC022 Double Row Spherical Roller Bearing

23122CCKC022 Double Row Spherical Roller Bearing

The 23122CCKC022 is a double-row spherical roller bearing with a 110mm bore and 180mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 101389 lbf and operates smoothly at speeds up to 800 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability under heavy loads. The open construction requires regular lubrication but works well in temperatures from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy machinery or industrial equipment where high radial loads and misalignment are common.

Weighing 5.75kg, it’s built for robust performance. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23122CCKC022
  • Brand TFL
  • Interchangeable SKF
  • Size 110 x 180 x 56 mm
  • Bore Dia 110 mm
  • Bore Dia Tolerance +0.035mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 56 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 122 mm
  • Shoulder/Recess Dia Of Outer Ring 166 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 101389 lbf
  • Static Radial Load 131513 lbf
  • Max Speed 800 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 5.75 kg
  • Price （US$） US$99.72

Features

Performance Features of 23122CCKC022 Bearing

23122CCKC022 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 101389 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 800 rpm, it delivers reliable performance in various industrial settings.

23122CCKC022 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its steel cage maintains roller alignment, enhancing durability and reducing maintenance needs.

Application

Industrial Uses of 23122CCKC022 Bearing
The 23122CCKC022 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. Its tapered bore ensures a secure fit, reducing slippage in demanding environments.

What Makes 23122CCKC022 Bearing a Preferred Choice?
With its chrome steel construction, 23122CCKC022 Bearing offers durability in applications like mining equipment and paper mills. The open design allows for easy lubrication, extending its service life even under continuous operation.

Built for Heavy-Duty Use: 23122CCKC022 Bearing
In construction equipment, 23122CCKC022 Bearing supports components like conveyor rollers and gearboxes, where its high load capacity is essential. The spherical roller design also compensates for minor misalignments, ensuring smooth performance.

Automotive vs Aerospace: Applications of 23122CCKC022 Bearing
While 23122CCKC022 Bearing is robust enough for truck transmissions, its precision also suits aerospace components like landing gear systems. The wide temperature range makes it adaptable to various operating conditions.

Perfect Fit for Automation: 23122CCKC022 Bearing
In automated production lines, 23122CCKC022 Bearing ensures reliable performance in robotic arms and assembly systems. Its steel cage provides stability, reducing maintenance needs in high-speed applications.
