23072 CACK/C083W507 Double Row Spherical Roller Bearing

23072 CACK/C083W507 Double Row Spherical Roller Bearing

The 23072 CACK/C083W507 is a double-row spherical roller bearing with a 360mm bore and 540mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 623395 lbf and runs smoothly at speeds up to 1200 RPM.

Its brass cage enhances durability, while the open design allows for easy lubrication. The bearing operates in temperatures from -30°C to 200°C, making it suitable for harsh environments.

With a tapered bore (1:12) and C3 radial clearance, it ensures secure fitting and reliable performance. Ideal for heavy machinery like crushers or industrial gearboxes where high radial loads are common.

Weighing 110kg, it’s a robust choice for demanding applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23072 CACK/C083W507
  • Brand TFL
  • Interchangeable SKF
  • Size 360 x 540 x 134 mm
  • Bore Dia 360 mm
  • Bore Dia Tolerance +0.057mm to 0
  • Outer Dia 540 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 134 mm
  • Width Tolerance -0.4mm to 0
  • Shoulder Dia Of Inner Ring 418 mm
  • Shoulder/Recess Dia Of Outer Ring 483 mm
  • Width Of Lubrication Groove 22.3 mm
  • Diameter Of Lubrication Hole 12 mm
  • Chamfer Dimension min.5 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 623395 lbf
  • Static Radial Load 1045362 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 110 kg
  • Price （US$） US$3,296.78

Features

Performance Features of 23072 CACK/C083W507 Bearing

23072 CACK/C083W507 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 623395 lbf, making it suitable for heavy-duty industrial applications.

The brass cage ensures smooth roller movement, reducing friction and enhancing durability.
With a maximum speed of 1200 rpm, it delivers reliable performance under demanding conditions.

23072 CACK/C083W507 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its tapered bore design simplifies installation and ensures secure fitting in various machinery.

The double-row spherical roller construction allows for slight misalignment adjustments.
This feature helps maintain performance even in less-than-ideal operating conditions.

23072 CACK/C083W507 Bearing requires regular lubrication for optimal performance.
Its open design facilitates easy maintenance and inspection during service intervals.

Application

Industrial Uses of 23072 CACK/C083W507 Bearing
23072 CACK/C083W507 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently.
The brass cage ensures smooth operation even under high stress, making it suitable for mining and construction equipment.

Where Is 23072 CACK/C083W507 Bearing Used?
You’ll often find 23072 CACK/C083W507 Bearing in wind turbines, where its tapered bore provides a secure fit for high-speed rotations.
Its chrome steel rollers and rings offer durability, essential for long-term performance in renewable energy applications.

Built for Heavy-Duty Use: 23072 CACK/C083W507 Bearing
23072 CACK/C083W507 Bearing excels in paper mills, supporting large rollers that require consistent alignment under heavy loads.
The C3 radial clearance allows for thermal expansion, making it reliable in high-temperature environments.

Automotive vs Aerospace: Applications of 23072 CACK/C083W507 Bearing
In automotive testing rigs, 23072 CACK/C083W507 Bearing handles combined loads during endurance trials.
For aerospace ground equipment, its precision and load capacity ensure smooth operation in hydraulic systems.

Key Fields for 23072 CACK/C083W507 Bearing
23072 CACK/C083W507 Bearing is ideal for steel plants, where its robust construction withstands extreme conditions.
The lubrication groove design simplifies maintenance, reducing downtime in continuous production lines.
