23072 CAC CO8 WJO4 Double Row Spherical Roller Bearing

23072 CAC CO8 WJO4 Double Row Spherical Roller Bearing

The 23072 CAC CO8 WJO4 is a double-row spherical roller bearing with a 360mm bore and 540mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 623395 lbf and runs smoothly at speeds up to 1200 RPM.

Its brass cage and open design ensure durability and easy lubrication, with a temperature range from -30°C to 200°C. The bearing features a 12mm lubrication hole and 22.3mm groove for convenient maintenance.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 110kg, it’s built to last while complying with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23072 CAC CO8 WJO4
  • Brand TFL
  • Interchangeable SKF
  • Size 360 x 540 x 134 mm
  • Bore Dia 360 mm
  • Bore Dia Tolerance -0.04mm to 0
  • Outer Dia 540 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 134 mm
  • Width Tolerance -0.4mm to 0
  • Shoulder Dia Of Inner Ring 418 mm
  • Shoulder/Recess Dia Of Outer Ring 483 mm
  • Width Of Lubrication Groove 22.3 mm
  • Diameter Of Lubrication Hole 12 mm
  • Chamfer Dimension min.5 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 623395 lbf
  • Static Radial Load 1045362 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 110 kg
  • Price （US$） US$2,535.84

Features

Performance Features of 23072 CAC CO8 WJO4 Bearing

23072 CAC CO8 WJO4 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 623395 lbf, making it suitable for heavy-duty applications.

The brass cage ensures proper roller alignment, reducing friction and enhancing durability.
With a maximum speed of 1200 rpm, it delivers reliable performance under demanding conditions.

23072 CAC CO8 WJO4 Bearing operates efficiently in temperatures ranging from -30° to 200 °C.
Its double-row spherical design accommodates misalignment, ensuring smooth operation in varied environments.

The lubrication groove and hole design facilitate easy maintenance, extending service life.
This bearing is ideal for applications requiring high load capacity and long-term reliability.

Application

Industrial Uses of 23072 CAC CO8 WJO4 Bearing
23072 CAC CO8 WJO4 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The brass cage ensures smooth operation even under high stress.

In wind turbines, 23072 CAC CO8 WJO4 Bearing supports the main shaft, thanks to its high dynamic radial load capacity. The chrome steel construction also withstands harsh weather conditions, making it reliable for renewable energy applications.

For mining equipment, 23072 CAC CO8 WJO4 Bearing’s spherical roller design accommodates misalignment, reducing wear in conveyor systems. Its lubrication groove simplifies maintenance, which is crucial in remote mining sites.

Where Is 23072 CAC CO8 WJO4 Bearing Used?
You’ll often find 23072 CAC CO8 WJO4 Bearing in paper mills, where its combined load capability suits roller presses. The wide temperature range ensures performance even in steam-heavy environments.

Built for Heavy-Duty Use: 23072 CAC CO8 WJO4 Bearing
23072 CAC CO8 WJO4 Bearing excels in steel plants, particularly in rolling mills where extreme loads are common. The cylindrical bore allows for secure fitting on large shafts.

Automotive vs Aerospace: Applications of 23072 CAC CO8 WJO4 Bearing
While 23072 CAC CO8 WJO4 Bearing isn’t typical in cars, it’s vital in aerospace ground equipment like cargo loaders. Its high static radial load capacity ensures safety during heavy lifting operations.
