23060 CCK/W33 Double Row Spherical Roller Bearing

23060 CCK/W33 Double Row Spherical Roller Bearing

The 23060 CCK/W33 is a double-row spherical roller bearing with a 300mm bore and 460mm outer diameter, built from sturdy chrome steel. It manages combined loads up to 498851 lbf and runs smoothly at speeds up to 1500 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The open construction requires regular lubrication, with grooves and holes for easy maintenance.

This bearing suits high-load applications like heavy machinery or industrial gearboxes, operating in temperatures from -30°C to 200°C. It’s interchangeable with SKF models, making replacements straightforward.

Weighing 68.5kg, it’s robust for demanding environments. Compliant with RoHS and REACH standards, it’s a reliable choice for engineers and maintenance teams.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23060 CCK/W33
  • Brand TFL
  • Interchangeable SKF
  • Size 300 x 460 x 118 mm
  • Bore Dia 300 mm
  • Bore Dia Tolerance +0.052mm to 0
  • Outer Dia 460 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 118 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 340 mm
  • Shoulder/Recess Dia Of Outer Ring 414 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 498851 lbf
  • Static Radial Load 775591 lbf
  • Max Speed 1500 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 68.5 kg
  • Price （US$） US$1,896.27

Features

Performance Features of 23060 CCK/W33 Bearing

23060 CCK/W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 498851 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 1500 rpm, it delivers reliable performance in demanding environments.

23060 CCK/W33 Bearing’s lubrication groove and hole design facilitate efficient grease distribution.
This extends service life and reduces maintenance needs, even in high-temperature settings up to 200°C.

Application

Industrial Uses of 23060 CCK/W33 Bearing
23060 CCK/W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads. The chrome steel construction ensures durability in harsh industrial environments.

Where Is 23060 CCK/W33 Bearing Used?
You’ll find 23060 CCK/W33 Bearing in mining equipment, where its high dynamic radial load capacity supports operations under extreme conditions. The taper bore design also simplifies installation in large shafts.

Built for Heavy-Duty Use: 23060 CCK/W33 Bearing
23060 CCK/W33 Bearing excels in paper mill machinery, handling combined loads with ease. Its steel cage and lubrication groove extend service life, reducing downtime for maintenance.

Automotive vs Aerospace: Applications of 23060 CCK/W33 Bearing
In automotive, 23060 CCK/W33 Bearing supports large drivetrain components, while in aerospace, it’s used in ground support equipment. The wide temperature range ensures reliability in both settings.

Essential Roles of 23060 CCK/W33 Bearing
23060 CCK/W33 Bearing is vital in wind turbines, where its spherical rollers accommodate shaft deflections. The open seal design allows for easy relubrication, keeping operations smooth.
