23040 CCK/C08W33 Double Row Spherical Roller Bearing

23040 CCK/C08W33 Double Row Spherical Roller Bearing

The 23040 CCK/C08W33 is a double-row spherical roller bearing with a 200mm bore and 310mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 237848 lbf and operates smoothly at speeds up to 2200 RPM.

Its spherical roller design accommodates misalignment, while the steel cage ensures durability. The bearing requires lubrication and performs well in temperatures from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a reliable replacement option. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 22.5kg, it’s built for demanding environments. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23040 CCK/C08W33
  • Brand TFL
  • Interchangeable SKF
  • Size 200 x 310 x 82 mm
  • Bore Dia 200 mm
  • Bore Dia Tolerance +0.04mm to 0
  • Outer Dia 310 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 82 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 228 mm
  • Shoulder/Recess Dia Of Outer Ring 278 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 237848 lbf
  • Static Radial Load 343958 lbf
  • Max Speed 2200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 22.5 kg

Features

Performance Features of 23040 CCK/C08W33 Bearing

23040 CCK/C08W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 237848 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2200 rpm, it delivers reliable performance in various industrial settings.

23040 CCK/C08W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its steel cage maintains roller alignment, reducing wear and extending service life.

The tapered bore design simplifies installation and ensures a secure fit.
Lubrication grooves and holes in 23040 CCK/C08W33 Bearing facilitate proper lubrication, enhancing durability.

Application

Industrial Uses of 23040 CCK/C08W33 Bearing
23040 CCK/C08W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The tapered bore ensures a secure fit, reducing slippage during high-load operations.

Where Is 23040 CCK/C08W33 Bearing Used?
In mining equipment, 23040 CCK/C08W33 Bearing provides reliable performance under extreme conditions, thanks to its chrome steel construction. The open design allows for easy lubrication, extending service life in dusty environments.

Built for Heavy-Duty Use: 23040 CCK/C08W33 Bearing
23040 CCK/C08W33 Bearing excels in paper mill machinery, where its high dynamic load capacity supports continuous operation. The steel cage enhances durability, making it suitable for long-term industrial use.

Automotive vs Aerospace: Applications of 23040 CCK/C08W33 Bearing
In large vehicles like trucks and buses, 23040 CCK/C08W33 Bearing ensures smooth performance in wheel hubs and transmissions. Its metric sizing and high-temperature tolerance also make it adaptable for aerospace auxiliary systems.

Essential Roles of 23040 CCK/C08W33 Bearing
For wind turbines, 23040 CCK/C08W33 Bearing’s spherical rollers accommodate misalignment, reducing wear in variable conditions. The lubrication groove design simplifies maintenance, crucial for remote installations.
