23040 CC/C2W33 Double Row Spherical Roller Bearing

23040 CC/C2W33 Double Row Spherical Roller Bearing

The 23040 CC/C2W33 is a double-row spherical roller bearing with a 200mm bore and 310mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 237848 lbf and operates smoothly at speeds up to 2200 RPM.

Its open design and steel cage ensure durability, while the C2 radial clearance allows for thermal expansion. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 22.5kg, it’s built to handle tough conditions. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23040 CC/C2W33
  • Brand TFL
  • Interchangeable SKF
  • Size 200 x 310 x 82 mm
  • Bore Dia 200 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 310 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 82 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 228 mm
  • Shoulder/Recess Dia Of Outer Ring 278 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 237848 lbf
  • Static Radial Load 343958 lbf
  • Max Speed 2200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 22.5 kg
  • Price （US$） US$487.47

Features

Performance Features of 23040 CC/C2W33 Bearing

23040 CC/C2W33 Bearing is built with chrome steel rings and rollers, ensuring strength and durability under heavy loads.
Its dynamic radial load capacity reaches 237,848 lbf, making it suitable for demanding industrial applications.

The double-row spherical roller design allows for combined load handling, providing versatility in various conditions.
With a maximum speed of 2,200 rpm, it balances performance and reliability in high-speed operations.

23040 CC/C2W33 Bearing operates efficiently in temperatures ranging from -30°C to 200°C.
Its steel cage maintains roller alignment, reducing friction and extending service life.

The lubrication groove and holes ensure proper grease distribution, enhancing smooth operation.
This design minimises maintenance needs while optimising performance in harsh environments.

Application

Industrial Uses of 23040 CC/C2W33 Bearing
23040 CC/C2W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads efficiently. The spherical roller construction also compensates for minor misalignments, reducing wear.

In automotive applications, 23040 CC/C2W33 Bearing supports large drivetrain components, such as truck axles, thanks to its high radial load capacity. The chrome steel rollers ensure durability even under constant stress.

For industrial fans and blowers, 23040 CC/C2W33 Bearing’s open design allows for easy lubrication, extending service life in high-temperature environments. Its C2 radial clearance provides optimal performance at varying speeds.

Where Is 23040 CC/C2W33 Bearing Used?
You’ll often find 23040 CC/C2W33 Bearing in mining equipment, where its robust construction withstands harsh conditions. The steel cage adds extra stability during heavy-load operations.

In paper mills, 23040 CC/C2W33 Bearing ensures smooth operation of large rollers, handling both radial and axial forces. Its metric sizing makes it compatible with standard European machinery.

Built for Heavy-Duty Use: 23040 CC/C2W33 Bearing
23040 CC/C2W33 Bearing excels in construction equipment like cranes, where its high static load capacity prevents premature failure. The lubrication groove design simplifies maintenance.

For wind turbines, 23040 CC/C2W33 Bearing’s temperature range (-30° to 200°C) makes it reliable in varying climates. The spherical rollers adapt to shaft deflections, reducing downtime.

Light-Duty vs Heavy-Duty: Best Uses for 23040 CC/C2W33 Bearing
In light-duty applications like conveyor systems, 23040 CC/C2W33 Bearing offers long life with minimal maintenance. Its open design allows for quick inspections.

For heavy-duty uses like steel mills, 23040 CC/C2W33 Bearing’s dynamic radial load rating ensures consistent performance. The chrome steel construction resists deformation under extreme pressure.
