23030 CCJ W33 C3 W509 Double Row Spherical Roller Bearing

23030 CCJ W33 C3 W509 Double Row Spherical Roller Bearing

The 23030 CCJ W33 C3 W509 is a double-row spherical roller bearing with a 150mm bore and 225mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 119374 lbf and operates smoothly at speeds up to 3200 RPM.

Its open design and lubrication groove make maintenance straightforward, while the steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 7.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23030 CCJ W33 C3 W509
  • Brand TFL
  • Interchangeable SKF
  • Size 150 x 225 x 56 mm
  • Bore Dia 150 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 225 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 56 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 169 mm
  • Shoulder/Recess Dia Of Outer Ring 203 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 119374 lbf
  • Static Radial Load 168607 lbf
  • Max Speed 3200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 7.65 kg
  • Price （US$） US$154.98

Features

Performance Features of 23030 CCJ W33 C3 W509 Bearing

23030 CCJ W33 C3 W509 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 119374 lbf, ensuring reliable operation under heavy stress.

The double-row spherical roller design allows for slight misalignment, maintaining smooth performance.
With a maximum speed of 3200 rpm, it balances durability and efficiency in demanding conditions.

23030 CCJ W33 C3 W509 Bearing’s C3 radial clearance ensures optimal performance under varying temperatures.
Its steel cage keeps the rollers aligned, reducing wear and extending service life.

The lubrication groove and holes in 23030 CCJ W33 C3 W509 Bearing ensure consistent lubrication.
This feature helps maintain smooth operation and reduces maintenance needs over time.

Application

Industrial Uses of 23030 CCJ W33 C3 W509 Bearing
23030 CCJ W33 C3 W509 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. The spherical roller construction also compensates for misalignment, ensuring smooth operation in demanding environments.

What Makes 23030 CCJ W33 C3 W509 Bearing a Preferred Choice?
In mining equipment, 23030 CCJ W33 C3 W509 Bearing’s robust chrome steel construction withstands extreme conditions, while the lubrication groove extends service life. Its C3 clearance allows for thermal expansion, making it ideal for high-temperature applications.

Built for Heavy-Duty Use: 23030 CCJ W33 C3 W509 Bearing
For wind turbines, 23030 CCJ W33 C3 W509 Bearing’s high dynamic load capacity ensures reliable performance under fluctuating forces. The steel cage provides added durability, reducing maintenance needs in remote installations.

Automotive vs Aerospace: Applications of 23030 CCJ W33 C3 W509 Bearing
In large trucks, 23030 CCJ W33 C3 W509 Bearing supports axles and transmissions, offering stability under heavy loads. While in aerospace, its precision and temperature range make it suitable for auxiliary systems requiring consistent performance.

Key Fields for 23030 CCJ W33 C3 W509 Bearing
23030 CCJ W33 C3 W509 Bearing is often found in paper mills, where its resistance to moisture and contaminants keeps production lines running. The open design also simplifies relubrication, minimising downtime in continuous operations.
