22334 CC/W513 Double Row Spherical Roller Bearing

22334 CC/W513 Double Row Spherical Roller Bearing

The 22334 CC/W513 is a double-row spherical roller bearing with a 170mm bore and 360mm outer diameter, built from sturdy chrome steel. It manages combined loads up to 418819 lbf and runs smoothly at speeds up to 1800 RPM.

Its open design requires regular lubrication, while the steel cage ensures durability. The bearing operates in temperatures from -30°C to 200°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 59kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and sustainable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22334 CC/W513
  • Brand TFL
  • Interchangeable SKF
  • Size 170 x 360 x 120 mm
  • Bore Dia 170 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 360 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 120 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 213 mm
  • Shoulder/Recess Dia Of Outer Ring 300 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 418819 lbf
  • Static Radial Load 485587 lbf
  • Max Speed 1800 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 59 kg
  • Price （US$） US$753.89

Features

Performance Features of 22334 CC/W513 Bearing

22334 CC/W513 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 418819 lbf, ensuring robust performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, maintaining smooth operation under stress.
With a maximum speed of 1800 rpm, it delivers both durability and efficiency.

22334 CC/W513 Bearing operates in temperatures from -30° to 200°C, suitable for various industrial environments.
The steel cage keeps the rollers aligned, reducing friction and extending service life.

Its lubrication groove and hole design ensure consistent oil distribution, minimising maintenance needs.
The standard radial clearance (CN) provides reliable performance under varying operational conditions.

Application

Industrial Uses of 22334 CC/W513 Bearing
The 22334 CC/W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads.
Its chrome steel construction ensures durability in harsh environments, making it a reliable choice for mining and construction equipment.

Where Is 22334 CC/W513 Bearing Used?
You’ll often find 22334 CC/W513 Bearing in wind turbines, where its ability to handle combined loads and high speeds is essential.
The open design allows for easy lubrication, ensuring smooth operation even in demanding conditions.

Built for Heavy-Duty Use: 22334 CC/W513 Bearing
In paper mills, 22334 CC/W513 Bearing supports rollers that endure constant stress and high temperatures.
Its steel cage and chrome steel rollers provide long-lasting performance, reducing downtime for maintenance.

Automotive vs Aerospace: Applications of 22334 CC/W513 Bearing
While 22334 CC/W513 Bearing isn’t typical in aerospace, it’s a staple in large commercial vehicles like buses and trucks.
Its robust design handles the heavy loads and vibrations common in transportation systems.

Key Fields for 22334 CC/W513 Bearing
The 22334 CC/W513 Bearing is ideal for steel plants, where it supports rolling mills under extreme heat and pressure.
Its metric sizing and high load capacity make it a versatile option for industrial applications worldwide.
