22330 CC/C3W513 Double Row Spherical Roller Bearing

22330 CC/C3W513 Double Row Spherical Roller Bearing

The 22330 CC/C3W513 is a double-row spherical roller bearing with a 150mm bore and 320mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 345981 lbf and operates smoothly at speeds up to 3100 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability under heavy loads. The bearing performs well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy machinery or industrial equipment where high radial and axial loads are present.

Weighing 42kg, it’s a robust option for demanding applications. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22330 CC/C3W513
  • Brand TFL
  • Interchangeable SKF
  • Size 150 x 320 x 108 mm
  • Bore Dia 150 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 320 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 108 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 188 mm
  • Shoulder/Recess Dia Of Outer Ring 266 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 345981 lbf
  • Static Radial Load 395664 lbf
  • Max Speed 3100 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 42 kg

Features

Performance Features of 22330 CC/C3W513 Bearing

22330 CC/C3W513 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 345981 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 3100 rpm, it delivers reliable performance in demanding environments.

22330 CC/C3W513 Bearing’s C3 radial clearance allows for thermal expansion in high-temperature settings.
The steel cage maintains roller alignment, reducing wear and extending service life.

This bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its open design simplifies lubrication, ensuring consistent performance over time.

Application

Industrial Uses of 22330 CC/C3W513 Bearing
22330 CC/C3W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads effectively. The spherical roller construction also compensates for minor misalignments, ensuring smooth operation.

What Makes 22330 CC/C3W513 Bearing a Preferred Choice?
In mining equipment, 22330 CC/C3W513 Bearing’s high dynamic radial load capacity makes it suitable for harsh environments. Its chrome steel rollers and steel cage provide durability, even under extreme conditions.

Built for Heavy-Duty Use: 22330 CC/C3W513 Bearing
For wind turbines, 22330 CC/C3W513 Bearing supports the main shaft, where its C3 radial clearance accommodates thermal expansion. The open design simplifies lubrication, extending service life.

Automotive vs Aerospace: Applications of 22330 CC/C3W513 Bearing
In large trucks, 22330 CC/C3W513 Bearing is often found in axle systems, handling both radial and thrust loads. Its metric sizing ensures compatibility with global vehicle standards.

Where Is 22330 CC/C3W513 Bearing Used?
In paper mills, 22330 CC/C3W513 Bearing’s high-speed capability and temperature resistance make it ideal for rollers. The steel cage and chrome steel components resist wear in humid conditions.
