22330 CC/C3W26 Double Row Spherical Roller Bearing

22330 CC/C3W26 Double Row Spherical Roller Bearing

The 22330 CC/C3W26 is a double-row spherical roller bearing with a 150mm bore and 320mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 345981 lbf and operates smoothly at speeds up to 3100 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability under heavy use. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

With a C3 radial clearance, it accommodates thermal expansion, making it suitable for high-load applications. Ideal for industrial machinery like gearboxes or crushers where robust performance is needed.

Weighing 42kg, it’s built for heavy-duty use and complies with RoHS and REACH standards for safety and environmental care.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22330 CC/C3W26
  • Brand TFL
  • Interchangeable SKF
  • Size 150 x 320 x 108 mm
  • Bore Dia 150 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 320 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 108 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 188 mm
  • Shoulder/Recess Dia Of Outer Ring 266 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 345981 lbf
  • Static Radial Load 395664 lbf
  • Max Speed 3100 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 42 kg

Features

How Does 22330 CC/C3W26 Bearing Handle Heavy Loads?

22330 CC/C3W26 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 345981 lbf, ensuring dependable performance in tough conditions.
The steel cage maintains roller alignment, reducing friction and extending operational life.
With a maximum speed of 3100 rpm, it delivers both durability and efficiency.

What Makes 22330 CC/C3W26 Bearing Suitable for High-Temperature Applications?

22330 CC/C3W26 Bearing operates effectively in temperatures ranging from -30° to 200°C.
Its chrome steel construction ensures stability and performance even under thermal stress.
The open design allows for easy lubrication, maintaining smooth operation in demanding environments.
This makes it ideal for applications where temperature fluctuations are common.

Engineered for Precision: 22330 CC/C3W26 Bearing

22330 CC/C3W26 Bearing features a double-row spherical roller design, enhancing load distribution.
The cylindrical bore ensures a secure fit, reducing misalignment risks.
Its C3 radial clearance provides optimal performance under varying operational conditions.
Precision engineering makes it a reliable choice for heavy-duty machinery.

Why Choose 22330 CC/C3W26 Bearing for Combined Loads?

22330 CC/C3W26 Bearing excels in handling both radial and thrust loads simultaneously.
The spherical roller design compensates for misalignment, ensuring smooth operation.
With a static radial load capacity of 395664 lbf, it offers exceptional reliability.
Its construction makes it suitable for applications requiring high load-bearing capabilities.

Optimized for Efficiency: 22330 CC/C3W26 Bearing

22330 CC/C3W26 Bearing’s lubrication groove and hole design ensure consistent oil distribution.
This reduces friction and wear, enhancing overall efficiency.
The steel cage and chrome steel rollers contribute to long service life.
Its design prioritises performance while minimising maintenance needs.

Application

Industrial Uses of 22330 CC/C3W26 Bearing
22330 CC/C3W26 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. The spherical roller construction also compensates for misalignment, ensuring reliable performance in tough conditions.

Where Is 22330 CC/C3W26 Bearing Used?
In mining equipment, 22330 CC/C3W26 Bearing supports large rotating shafts, thanks to its robust chrome steel construction. Its C3 radial clearance allows for thermal expansion, making it suitable for high-temperature environments.

Built for Heavy-Duty Use: 22330 CC/C3W26 Bearing
This bearing excels in paper mills and steel plants, where its steel cage and lubrication groove extend service life. The 320 mm outer diameter provides stability for large-scale industrial applications.

Automotive vs Aerospace: Applications of 22330 CC/C3W26 Bearing
While 22330 CC/C3W26 Bearing isn’t typical in aerospace, it’s ideal for heavy vehicles like trucks and buses. Its combined load capacity handles both radial and thrust forces in drivetrain components.

Key Fields for 22330 CC/C3W26 Bearing
Wind turbines benefit from 22330 CC/C3W26 Bearing’s ability to withstand variable loads and misalignment. The 150 mm bore fits standard shafts, simplifying maintenance in remote installations.
