22326 CCK C3 Double Row Spherical Roller Bearing

22326 CCK C3 Double Row Spherical Roller Bearing

The 22326 CCK C3 is a double-row spherical roller bearing with a 130mm bore and 280mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 264375 lbf and operates smoothly at speeds up to 3600 RPM.

Its spherical roller design accommodates misalignment, while the steel cage ensures durability. The open construction allows for easy lubrication, with a 9mm hole for convenient greasing.

This bearing suits high-load applications like heavy machinery or industrial gearboxes, where reliability is key. It works in temperatures from -30°C to 200°C, making it versatile for various environments.

Weighing 28kg, it’s built for heavy-duty use. Compliant with RoHS and REACH standards, it’s a dependable choice for replacements, interchangeable with SKF models.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22326 CCK C3
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 280 x 93 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance +0.04mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 93 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 164 mm
  • Shoulder/Recess Dia Of Outer Ring 233 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 264375 lbf
  • Static Radial Load 296748 lbf
  • Max Speed 3600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 28 kg
  • Price （US$） US$297.00

Features

Performance Features of 22326 CCK C3 Bearing

22326 CCK C3 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 264375 lbf, ensuring reliable operation in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 3600 rpm, it maintains performance under demanding conditions.

22326 CCK C3 Bearing operates in temperatures from -30° to 200°C, suitable for various industrial environments.
The C3 radial clearance provides flexibility, accommodating thermal expansion during operation.

The steel cage keeps the rollers aligned, enhancing durability and reducing maintenance needs.
Its tapered bore design simplifies installation, ensuring a secure fit on the shaft.

Application

Industrial Uses of 22326 CCK C3 Bearing
The 22326 CCK C3 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads efficiently. Its tapered bore ensures a secure fit, reducing slippage during high-stress operations.

What Makes 22326 CCK C3 Bearing a Preferred Choice?
With a dynamic radial load capacity of 264375 lbf, 22326 CCK C3 Bearing excels in applications like gearboxes and industrial fans. The chrome steel construction offers durability, while the C3 clearance accommodates thermal expansion in demanding environments.

Built for Heavy-Duty Use: 22326 CCK C3 Bearing
In mining equipment, 22326 CCK C3 Bearing withstands harsh conditions thanks to its spherical roller design and steel cage. The lubrication groove and hole simplify maintenance, extending service life in continuous operations.

Automotive vs Aerospace: Applications of 22326 CCK C3 Bearing
While 22326 CCK C3 Bearing suits heavy vehicles like trucks and buses, its high-temperature tolerance also makes it viable for aerospace auxiliary systems. The metric sizing ensures compatibility across diverse machinery standards.

Perfect Fit for Automation: 22326 CCK C3 Bearing
In automated production lines, 22326 CCK C3 Bearing supports robotic arms and conveyor systems with smooth rotation. Its open design allows for easy lubrication, ensuring consistent performance in high-speed scenarios.
