22326 CCJA/W33VA405 Double Row Spherical Roller Bearing

22326 CCJA/W33VA405 Double Row Spherical Roller Bearing

The 22326 CCJA/W33VA405 is a double-row spherical roller bearing with a 130mm bore and 280mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 264375 lbf and operates smoothly at speeds up to 2400 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The open construction requires lubrication, with grooves and holes for easy maintenance.

This bearing suits heavy-duty applications like industrial gearboxes or mining equipment, where high radial loads and misalignment are common. It works in temperatures from -30°C to 200°C.

Weighing 29kg, it’s a robust choice for demanding environments. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22326 CCJA/W33VA405
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 280 x 93 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 93 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 164 mm
  • Shoulder/Recess Dia Of Outer Ring 233 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 264375 lbf
  • Static Radial Load 296748 lbf
  • Max Speed 2400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 29 kg
  • Price （US$） US$400.64

Features

How Does 22326 CCJA/W33VA405 Bearing Handle Combined Loads?

22326 CCJA/W33VA405 Bearing features a double-row spherical roller design, ideal for handling both radial and axial loads.
Its chrome steel construction ensures durability under high dynamic radial loads of up to 264375 lbf.

The steel cage maintains roller alignment, reducing friction and extending operational life.
With a maximum speed of 2400 rpm, it performs reliably in demanding industrial applications.

22326 CCJA/W33VA405 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its lubrication groove and hole design ensure consistent performance with minimal maintenance.

Application

Industrial Uses of 22326 CCJA/W33VA405 Bearing
22326 CCJA/W33VA405 Bearing is commonly used in heavy machinery like crushers and mining equipment, where its double-row design handles high radial and axial loads. The spherical roller type ensures smooth operation even with slight misalignments.

Where Is 22326 CCJA/W33VA405 Bearing Used?
You’ll often find 22326 CCJA/W33VA405 Bearing in wind turbines, where its robust construction withstands variable loads and harsh conditions. The W33 lubrication groove also simplifies maintenance in hard-to-reach locations.

Built for Heavy-Duty Use: 22326 CCJA/W33VA405 Bearing
22326 CCJA/W33VA405 Bearing excels in steel mills and paper processing plants, thanks to its chrome steel rollers and high-temperature tolerance. Its open design allows for easy relubrication, extending service life.

Automotive vs Aerospace: Applications of 22326 CCJA/W33VA405 Bearing
In automotive applications, 22326 CCJA/W33VA405 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring reliability. The metric sizing ensures compatibility across industries.

Perfect Fit for Automation: 22326 CCJA/W33VA405 Bearing
22326 CCJA/W33VA405 Bearing is ideal for robotic arms in manufacturing, where its high load capacity and precision are crucial. The steel cage provides durability in continuous operation scenarios.
