22324 CC/C401W33 Double Row Spherical Roller Bearing

22324 CC/C401W33 Double Row Spherical Roller Bearing

The 22324 CC/C401W33 is a double-row spherical roller bearing with a 120mm bore and 260mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 22908 lbf and runs smoothly at speeds up to 3900 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability under heavy loads. The open construction requires regular lubrication for optimal performance.

This bearing operates in temperatures from -30°C to 200°C, making it suitable for harsh environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 22.5kg, it’s robust for industrial use. Ideal for applications like heavy machinery or conveyor systems where high radial loads and misalignment are common. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22324 CC/C401W33
  • Brand TFL
  • Interchangeable SKF
  • Size 120 x 260 x 86 mm
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 260 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 86 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 152 mm
  • Shoulder/Recess Dia Of Outer Ring 216 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 22908 lbf
  • Static Radial Load 251786 lbf
  • Max Speed 3900 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C4
  • RoHs Compliant
  • REACH Compliant
  • Weight 22.5 kg
  • Price （US$） US$328.07

Features

Performance Features of 22324 CC/C401W33 Bearing

22324 CC/C401W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22908 lbf, ensuring reliable performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
This feature enhances durability and extends the service life even under challenging conditions.

22324 CC/C401W33 Bearing operates efficiently within a temperature range of -30° to 200 °C.
Its steel cage maintains roller alignment, ensuring smooth operation at speeds up to 3900 rpm.

With a C4 radial clearance, this bearing accommodates thermal expansion in high-temperature environments.
The lubrication groove and holes facilitate easy maintenance, keeping performance consistent over time.

Application

Industrial Uses of 22324 CC/C401W33 Bearing
The 22324 CC/C401W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads effectively. Its chrome steel construction ensures durability even in harsh operating conditions.

Where Is 22324 CC/C401W33 Bearing Used?
You’ll often find the 22324 CC/C401W33 Bearing in mining equipment, where its high load capacity and resistance to misalignment are crucial. The open design allows for easy lubrication, extending its service life in demanding environments.

Built for Heavy-Duty Use: 22324 CC/C401W33 Bearing
This bearing excels in paper mills and steel plants, where continuous operation under heavy loads is required. The C4 radial clearance ensures optimal performance even with thermal expansion.

Automotive vs Aerospace: Applications of 22324 CC/C401W33 Bearing
In automotive applications, the 22324 CC/C401W33 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring high reliability. Its metric sizing makes it versatile across industries.

Practical Applications of 22324 CC/C401W33 Bearing
The 22324 CC/C401W33 Bearing is ideal for wind turbines, where its spherical roller design accommodates shaft misalignment. The steel cage provides stability during high-speed rotations.
