22319 CC Double Row Spherical Roller Bearing

22319 CC Double Row Spherical Roller Bearing

The 22319 CC is a double-row spherical roller bearing with a 95mm bore and 200mm outer diameter, crafted from robust chrome steel. It handles combined loads up to 157141 lbf and operates smoothly at speeds up to 3400 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing performs well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a reliable replacement option. Ideal for heavy-duty applications like industrial machinery or construction equipment where high radial loads are common.

Weighing 10kg, it’s built to last and complies with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22319 CC
  • Brand TFL
  • Interchangeable SKF
  • Size 95 x 200 x 67 mm
  • Bore Dia 95 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 67 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 118 mm
  • Shoulder/Recess Dia Of Outer Ring 168 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 157141 lbf
  • Static Radial Load 171979 lbf
  • Max Speed 3400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 10 kg
  • Price （US$） 125.46

Features

Performance Features of 22319 CC Bearing

22319 CC Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 157141 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 3400 rpm, it delivers reliable performance in various industrial settings.

22319 CC Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its steel cage maintains roller alignment, reducing friction and extending service life.

The lubrication groove and hole design in 22319 CC Bearing ensure consistent grease distribution.
This feature minimises maintenance needs while enhancing operational reliability.

Application

Industrial Uses of 22319 CC Bearing
The 22319 CC Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads. Its chrome steel construction ensures durability in harsh industrial environments.

Where Is 22319 CC Bearing Used?
You’ll often find 22319 CC Bearing in mining equipment, where its high dynamic load capacity keeps operations running smoothly. The open design allows for easy lubrication, extending its service life in demanding conditions.

Built for Heavy-Duty Use: 22319 CC Bearing
22319 CC Bearing excels in construction equipment like cranes and excavators, thanks to its robust steel cage and spherical roller design. It’s also a reliable choice for wind turbines, where consistent performance under variable loads is essential.

Automotive vs Aerospace: Applications of 22319 CC Bearing
In automotive applications, 22319 CC Bearing supports heavy axles and transmissions, while in aerospace, it’s used in landing gear systems. Its wide temperature range makes it versatile for both ground and high-altitude operations.

Practical Applications of 22319 CC Bearing
For conveyor systems in factories, 22319 CC Bearing provides smooth operation under heavy loads. Its metric sizing ensures compatibility with a range of industrial equipment, making it a go-to for maintenance teams.
