22315 CCY Double Row Spherical Roller Bearing

22315 CCY Double Row Spherical Roller Bearing

The 22315 CCY is a double-row spherical roller bearing with a 75mm bore and 160mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 103862 lbf and operates smoothly at speeds up to 4300 RPM.

Its brass cage and open design ensure durability and easy lubrication, with a temperature range from -30°C to 200°C. The bearing features a lubrication groove and holes for convenient maintenance.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 5.25kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22315 CCY
  • Brand TFL
  • Interchangeable SKF
  • Size 75 x 160 x 55 mm
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 55 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 92.8 mm
  • Shoulder/Recess Dia Of Outer Ring 135 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 103862 lbf
  • Static Radial Load 106784 lbf
  • Max Speed 4300 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 5.25 kg
  • Price （US$） 86.4

Features

Performance Features of 22315 CCY Bearing

22315 CCY Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 103862 lbf, making it suitable for heavy-duty applications.

The brass cage ensures proper roller alignment, reducing friction and enhancing durability.
With a maximum speed of 4300 rpm, it delivers reliable performance under demanding conditions.

22315 CCY Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its double-row spherical design accommodates misalignment, ensuring smooth operation.

The lubrication groove and hole design in 22315 CCY Bearing simplify maintenance.
This feature helps extend service life while reducing operational downtime.

Application

Industrial Uses of 22315 CCY Bearing
The 22315 CCY Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads.
Its brass cage and chrome steel construction ensure durability in harsh industrial environments, making it a reliable choice for long-term use.

Where Is 22315 CCY Bearing Used?
In mining equipment, 22315 CCY Bearing supports high-load applications such as conveyor systems and pulverisers.
The metric sizing and open design simplify maintenance, while the lubrication groove extends service life in dusty conditions.

Built for Heavy-Duty Use: 22315 CCY Bearing
22315 CCY Bearing excels in construction machinery, particularly in cranes and excavators, where combined loads are frequent.
The spherical roller design accommodates shaft deflection, reducing wear and tear under dynamic stress.

Automotive vs Aerospace: Applications of 22315 CCY Bearing
In automotive systems, 22315 CCY Bearing is found in heavy trucks and buses, handling high radial and axial loads.
For aerospace, its temperature range and precision make it suitable for auxiliary equipment, though not primary flight systems.

Key Fields for 22315 CCY Bearing
22315 CCY Bearing is ideal for wind turbines, where its ability to handle misalignment and heavy loads ensures consistent performance.
The brass cage reduces friction, while the chrome steel rollers provide excellent resistance to fatigue in variable weather conditions.
