22234 CC/C3W33 Double Row Spherical Roller Bearing

22234 CC/C3W33 Double Row Spherical Roller Bearing

The 22234 CC/C3W33 is a double-row spherical roller bearing with a 170mm bore and 310mm outer diameter, crafted from robust chrome steel. It manages combined loads up to 265949 lbf and operates smoothly at speeds up to 2600 RPM.

Its open design and steel cage ensure durability, while the C3 radial clearance allows for thermal expansion. The bearing includes lubrication grooves and holes for easy maintenance.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment.

Weighing 28kg, it’s built to handle demanding conditions, with a temperature range from -30°C to 200°C. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22234 CC/C3W33
  • Brand TFL
  • Interchangeable SKF
  • Size 170 x 310 x 86 mm
  • Bore Dia 170 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 310 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 86 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 203 mm
  • Shoulder/Recess Dia Of Outer Ring 267 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 265949 lbf
  • Static Radial Load 328221 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 28 kg
  • Price （US$） US$418.39

Features

Performance Features of 22234 CC/C3W33 Bearing

22234 CC/C3W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 265949 lbf, ensuring robust performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, maintaining smooth operation.
With a maximum speed of 2600 rpm, it delivers both durability and efficiency.

22234 CC/C3W33 Bearing operates in temperatures from -30° to 200°C, suitable for varied environments.
The C3 radial clearance ensures optimal performance under thermal expansion.

Its steel cage keeps rollers aligned, reducing wear and extending service life.
The lubrication groove and holes facilitate consistent grease distribution, lowering maintenance needs.

Application

Industrial Uses of 22234 CC/C3W33 Bearing
22234 CC/C3W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads effortlessly. The spherical roller construction also compensates for minor misalignments, ensuring smooth operation in rugged environments.

Where Is 22234 CC/C3W33 Bearing Used?
In mining equipment, 22234 CC/C3W33 Bearing supports large rotating shafts, thanks to its robust chrome steel construction and high dynamic load capacity. The C3 radial clearance further accommodates thermal expansion, making it reliable in extreme conditions.

Built for Heavy-Duty Use: 22234 CC/C3W33 Bearing
For paper mill machinery, 22234 CC/C3W33 Bearing’s steel cage and lubrication grooves reduce friction, extending service life even under constant stress. Its wide temperature range (-30° to 200°C) suits both hot and cold processing stages.

Automotive vs Aerospace: Applications of 22234 CC/C3W33 Bearing
While 22234 CC/C3W33 Bearing isn’t typical in cars, it’s ideal for aerospace landing gear systems due to its shock absorption and load distribution capabilities. The metric sizing ensures compatibility with international engineering standards.

Essential Roles of 22234 CC/C3W33 Bearing
In wind turbines, 22234 CC/C3W33 Bearing’s self-aligning feature and high-speed tolerance (2600 rpm) make it a go-to for nacelle assemblies. The open design simplifies relubrication, crucial for remote maintenance.
