22216 CCR W33 Double Row Spherical Roller Bearing

22216 CCR W33 Double Row Spherical Roller Bearing

The 22216 CCR W33 is a double-row spherical roller bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 54629 lbf and operates smoothly at speeds up to 6000 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The bearing includes a lubrication groove and hole for easy maintenance.

Suitable for heavy-duty applications like industrial gearboxes or mining equipment, it performs well in temperatures from -30°C to 200°C.

Weighing 2.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for demanding environments.

Interchangeable with SKF bearings, it offers a practical solution for replacements or upgrades. Ideal for machinery where high radial loads and misalignment are common.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22216 CCR W33
  • Brand TFL
  • Interchangeable SKF
  • Size 80 x 140 x 33 mm
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 94.7 mm
  • Shoulder/Recess Dia Of Outer Ring 124 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 54629 lbf
  • Static Radial Load 60698 lbf
  • Max Speed 6000 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 2.1 kg
  • Price （US$） 50.94

Features

How Does 22216 CCR W33 Bearing Handle Combined Loads?

22216 CCR W33 Bearing features a double-row spherical roller design, ideal for managing both radial and axial loads.
Its chrome steel construction ensures high strength and durability under heavy dynamic radial loads up to 54629 lbf.

The steel cage maintains roller alignment, reducing friction and wear for smoother operation.
With a maximum speed of 6000 rpm, it delivers reliable performance in demanding conditions.

22216 CCR W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its lubrication groove and hole design ensure consistent performance with minimal maintenance.

Application

Common Applications of 22216 CCR W33 Bearing
22216 CCR W33 Bearing is widely used in heavy machinery, such as mining equipment and construction vehicles, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction ensures smooth operation even in misaligned conditions.

In industrial settings, 22216 CCR W33 Bearing supports conveyor systems and gearboxes, thanks to its high dynamic load capacity. The chrome steel material provides excellent durability in demanding environments.

For wind turbines, 22216 CCR W33 Bearing’s ability to withstand high speeds and heavy loads makes it a reliable choice. The lubrication groove design ensures consistent performance over long periods.

Automotive applications like truck wheel hubs benefit from 22216 CCR W33 Bearing’s robust construction. Its metric sizing and compatibility with SKF models make it a versatile option for various vehicle types.

In paper mills, 22216 CCR W33 Bearing’s resistance to high temperatures and heavy loads ensures reliable operation. The steel cage enhances stability, reducing wear in continuous-use scenarios.
