22216 CCK W33 C3 Double Row Spherical Roller Bearing

22216 CCK W33 C3 Double Row Spherical Roller Bearing

The 22216 CCK W33 C3 is a double-row spherical roller bearing with an 80mm bore and 140mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 54629 lbf and operates smoothly at speeds up to 6000 RPM.

Its spherical roller design accommodates misalignment, while the steel cage ensures reliable performance. The open structure allows for easy lubrication, with a groove and hole for efficient maintenance.

This bearing suits high-load applications like industrial gearboxes or heavy machinery, where alignment flexibility is key. It works in temperatures from -30°C to 200°C, making it versatile for various environments.

Weighing 2.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a dependable choice for replacements, interchangeable with SKF models.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22216 CCK W33 C3
  • Brand TFL
  • Interchangeable SKF
  • Size 80 x 140 x 33 mm
  • Bore Dia 80 mm
  • Bore Dia Tolerance +0.03mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 94.7 mm
  • Shoulder/Recess Dia Of Outer Ring 124 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 54629 lbf
  • Static Radial Load 60698 lbf
  • Max Speed 6000 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 2.1 kg
  • Price （US$） 50.94

Features

Performance Features of 22216 CCK W33 C3 Bearing

22216 CCK W33 C3 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 54629 lbf, ensuring robust performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 6000 rpm, it maintains efficiency even under demanding conditions.

22216 CCK W33 C3 Bearing includes a lubrication groove and hole for consistent performance.
Its C3 radial clearance ensures smooth operation across a wide temperature range.

Application

Industrial Uses of 22216 CCK W33 C3 Bearing
22216 CCK W33 C3 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction also compensates for minor misalignments, ensuring smooth operation in rugged environments.

What Makes 22216 CCK W33 C3 Bearing a Preferred Choice?
In mining equipment, 22216 CCK W33 C3 Bearing’s high dynamic load capacity makes it ideal for conveyor systems and gearboxes. The W33 lubrication groove ensures consistent performance even under extreme conditions.

Built for Heavy-Duty Use: 22216 CCK W33 C3 Bearing
For wind turbines, 22216 CCK W33 C3 Bearing’s tapered bore design simplifies installation and maintenance. Its C3 radial clearance accommodates thermal expansion, making it reliable in fluctuating temperatures.

Automotive vs Aerospace: Applications of 22216 CCK W33 C3 Bearing
In truck wheel hubs, 22216 CCK W33 C3 Bearing provides durability under heavy loads, while its precision suits aerospace actuators. The chrome steel construction ensures longevity in both high-stress and high-speed scenarios.

Perfect Fit for Automation: 22216 CCK W33 C3 Bearing
22216 CCK W33 C3 Bearing works well in robotic arms, where its low friction and high-speed capability enhance precision. The steel cage adds stability, making it suitable for repetitive movements.
