22209E/C3 E C3 W33 Double Row Spherical Roller Bearing

Brand: TFL Bearing Interchangeable: SKF 22209E/C3 E C3 W33 45 x 85 x 23 mm Metric Open
Part number: 22209E/C3 E C3 W33
In Stock
US$27.36 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia45 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia85 mm
Outer Dia Tolerance-0.015mm to 0
Width23 mm
Width Tolerance-0.06mm to 0
Shoulder Dia Of Inner Ring54.4 mm
Shoulder/Recess Dia Of Outer Ring74.4 mm
Width Of Lubrication Groove5.5 mm
Diameter Of Lubrication Hole3 mm
Chamfer Dimensionmin.1.1 mm
Performance
Dynamic Radial Load2,338 lbf
Static Radial Load22,031 lbf
Max Speed10,000 rpm
Temperature Range-30° to 200 °C
Characteristics
System of MeasurementMetric
Radial run-outStandard
Bearing TypeRoller
Roller Bearing TypeSpherical
Bore TypeCylindrical
For Load DirectionCombined
ConstructionDouble Row
Seal TypeOpen
LubricationRequired
Radial ClearanceC3
Weight0.57 kg
Material
Ring MaterialChrome Steel
Roller MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHsCompliant
REACHCompliant
Product photo
22209E/C3 E C3 W33 Double Row Spherical Roller Bearing

Description

The 22209E/C3 is a double-row spherical roller bearing with a 45mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 2338 lbf and reaches speeds of 10000 RPM.

Its spherical rollers and C3 radial clearance allow smooth operation even under misalignment, while the steel cage enhances durability. The open design requires regular lubrication for optimal performance.

This bearing suits high-load applications like industrial gearboxes or heavy machinery, handling temperatures from -30°C to 200°C. It’s interchangeable with SKF models for easy replacement.

Weighing 0.57kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for demanding environments.

Features

Performance Features of 22209E/C3 E C3 W33 Bearing

22209E/C3 E C3 W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 2338 lbf, ensuring reliable performance in various applications.

The double-row spherical roller design allows for smooth operation even under misalignment conditions.
With a maximum speed of 10,000 rpm, it delivers both durability and efficiency.

22209E/C3 E C3 W33 Bearing operates in temperatures from -30° to 200°C, making it suitable for demanding environments.
The C3 radial clearance provides optimal performance under varying thermal conditions.

Steel cage construction maintains roller alignment, reducing wear and extending service life.
Its lubrication groove and hole design ensure consistent performance with minimal maintenance.

Application

Industrial Uses of 22209E/C3 E C3 W33 Bearing
22209E/C3 E C3 W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial loads with ease. The spherical roller construction also compensates for minor misalignments, reducing wear in rugged environments.

Where Is 22209E/C3 E C3 W33 Bearing Used?
In mining equipment, 22209E/C3 E C3 W33 Bearing excels under extreme conditions, thanks to its robust chrome steel rollers and steel cage. Its C3 radial clearance ensures reliable performance even with thermal expansion in high-temperature operations.

Built for Heavy-Duty Use: 22209E/C3 E C3 W33 Bearing
This bearing is a go-to for conveyor systems in manufacturing plants, where its lubrication groove design extends service life. The metric sizing makes it a seamless fit for European and Asian industrial equipment.

Automotive vs Aerospace: Applications of 22209E/C3 E C3 W33 Bearing
In automotive drivetrains, 22209E/C3 E C3 W33 Bearing supports heavy loads in gearboxes, while its high-speed capability suits aerospace auxiliary systems. The temperature range up to 200°C adds versatility across sectors.

Perfect Fit for Automation: 22209E/C3 E C3 W33 Bearing
Robotic arms benefit from 22209E/C3 E C3 W33 Bearing’s smooth rotation and load adaptability in automated assembly lines. The open seal design simplifies relubrication, minimising downtime in continuous operations.
