22209 E C3 W33 Double Row Spherical Roller Bearing

22209 E C3 W33 Double Row Spherical Roller Bearing

The 22209 E C3 W33 is a double-row spherical roller bearing with a 45mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 2338 lbf and can spin at speeds up to 10000 RPM.

Its open design and C3 radial clearance allow for smooth operation under varying temperatures, from -30°C to 200°C. The steel cage and chrome steel rollers ensure durability and long service life.

This bearing features lubrication grooves and holes, making maintenance straightforward. It’s interchangeable with SKF models, ideal for heavy-duty applications like industrial gearboxes or mining equipment.

Weighing 0.57kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for demanding environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22209 E C3 W33
  • Brand TFL
  • Interchangeable SKF
  • Size 45 x 85 x 23 mm
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 54.4 mm
  • Shoulder/Recess Dia Of Outer Ring 74.4 mm
  • Width Of Lubrication Groove 5.5 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.1.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 2338 lbf
  • Static Radial Load 22031 lbf
  • Max Speed 10000 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 0.57 kg
  • Price （US$） 25.92

Features

Performance Features of 22209 E C3 W33 Bearing

22209 E C3 W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 2338 lbf, ensuring reliable performance in various applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 10,000 rpm, it delivers both durability and efficiency.

22209 E C3 W33 Bearing operates in temperatures from -30° to 200°C, making it suitable for demanding environments.
The C3 radial clearance provides flexibility in different operating conditions.

Application

Industrial Uses of 22209 E C3 W33 Bearing
The 22209 E C3 W33 Bearing is commonly used in heavy machinery like conveyors and crushers, where its double-row design handles both radial and axial loads efficiently.
Its spherical rollers compensate for misalignment, making it suitable for rugged environments where precision is still needed.

Where Is 22209 E C3 W33 Bearing Used?
You’ll find the 22209 E C3 W33 Bearing in automotive applications like truck wheel hubs, where its high load capacity ensures durability.
The C3 radial clearance also helps accommodate thermal expansion during long drives.

Built for Heavy-Duty Use: 22209 E C3 W33 Bearing
This bearing excels in industrial fans and pumps, thanks to its steel cage and chrome steel rollers that resist wear.
The lubrication groove ensures smooth operation even at high speeds, up to 10000 rpm.

Automotive vs Industrial: Applications of 22209 E C3 W33 Bearing
In trucks, the 22209 E C3 W33 Bearing supports heavy loads, while in mining equipment, it handles harsh conditions with ease.
Its temperature range of -30° to 200°C makes it versatile for both cold and hot environments.

Perfect Fit for Automation: 22209 E C3 W33 Bearing
The 22209 E C3 W33 Bearing works well in robotic arms, where its spherical rollers allow for slight misalignments.
Its open design simplifies lubrication, keeping maintenance straightforward in automated systems.
