19268X Single Cups (Imperial)

19268X Single Cups (Imperial)

The 19268X is a single cup tapered roller bearing with an outer diameter of 2.688″ and a width of 0.6312″, made from sturdy chrome steel. It fits well with Timken bearings, making it a handy replacement option.

Designed for standard use, it handles temperatures from -30°C to 110°C, suitable for various industrial conditions. The ABEC-1 rating ensures reliable performance for general applications.

Its tapered design helps distribute loads evenly, reducing wear over time. The cup’s precise dimensions ensure a snug fit in assemblies.

Ideal for machinery requiring tapered roller bearings, such as gearboxes or wheel hubs. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 19268X
  • Brand TFL
  • Interchangeable Timken
  • Size 2.36" x 2.688" x 0.6312"
  • Outer Dia 2.688"
  • Outer Dia Tolerance +0.001" to 0
  • Cup Width 0.6312"
  • Cup Width Tolerance +0.002" to -0.01
  • Cup Backface ToClear Radius 0.06"
  • Cup Frontface Backing Diameter 2.60"
  • Cup Backface Backing Diameter 2.36"
  • System of Measurement Inch
  • Roller Bearing Type Tapered
  • Type Cups
  • Bearing Part Number 19138X-19268X
  • Cups Type Standard
  • Series 19000
  • Ring Material Chrome Steel
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
  • REACH Compliant

Features

Why Choose 19268X Bearing for Precision Tasks?

19268X Bearing is crafted from chrome steel, offering excellent durability and resistance to wear.
Its tapered roller design ensures precise alignment, making it ideal for high-accuracy applications.

The standard cup type and ABEC-1 rating provide reliable performance in various industrial settings.
With a temperature range of -30° to 110°C, it maintains stability in both cold and warm environments.

The 19268X Bearing’s dimensions and tolerances are finely tuned for consistent operation.
Its interchangeability with Timken bearings adds convenience for replacements and upgrades.

Application

Industrial Uses of 19268X Bearing
19268X Bearing is commonly used in heavy machinery, such as construction equipment and agricultural vehicles, where its tapered design handles radial and axial loads efficiently. The chrome steel construction ensures durability in tough working conditions.

What Makes 19268X Bearing a Preferred Choice?
In automotive applications, 19268X Bearing fits well in wheel hubs and differential systems, providing reliable performance under varying loads. Its inch sizing makes it compatible with many North American vehicle models.

Built for Heavy-Duty Use: 19268X Bearing
For industrial conveyor systems, 19268X Bearing offers smooth operation and long service life, even in high-load environments. The standard cup design simplifies installation and maintenance.

Automotive vs Industrial: Applications of 19268X Bearing
19268X Bearing is versatile, working equally well in truck axles and factory machinery. Its ABEC-1 rating ensures consistent performance without unnecessary precision costs.

Where Is 19268X Bearing Used?
You’ll find 19268X Bearing in gearboxes and power transmission systems, where its tapered rollers manage combined loads effectively. The temperature range suits most typical operating environments.
