TS (Single Row Tapered Roller Bearings) (Imperial) 536-534

TS (Single Row Tapered Roller Bearings) (Imperial) 536-534

The 536-534 is a single-row tapered roller bearing with a 1.875″ bore and 4.3307″ outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 38700 lbf radially and 5090 lbf thrust-wise, suitable for moderate-speed applications.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for use in gearboxes, axles, or industrial machinery where combined loads are common.

Weighing 3.6 lb, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe usage.

The 536-534 features standard radial clearance, with options for C3, C4, or C5 if needed. Its ABEC-1 rating ensures reliable performance for general industrial applications.

The tapered roller design provides effective load distribution, reducing wear over time. The chrome steel rollers and rings enhance longevity even under heavy use.

With a cone width of 1.455″ and cup width of 1.0625″, it fits snugly in most standard housings. The clearances and backing diameters are designed for easy installation and alignment.

Perfect for maintenance tasks or new installations, this bearing offers a balance of strength and precision. Its compatibility with Timken parts adds to its versatility in various mechanical setups.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 536-534
  • Brand TFL
  • Interchangeable Timken
  • Size 1.875" x 4.3307" x 1.3437"
  • Bore Dia 1.875"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 4.3307"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1.455"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 1.0625"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 1.3437"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.14"
  • Cup Backface ToClear Radius 0.130"
  • Cone Frontface Backing Diameter 2.2"
  • Cone Backface Backing Diameter 2.44"
  • Cup Frontface Backing Diameter 3.96"
  • Cup Backface Backing Diameter 3.70"
  • Cage Cone Frontface Clearance 0.07"
  • Cage Cone Backface Clearance 0.08"
  • Effective Center Location -0.48"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 536
  • Cup Part Number 534
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 535
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 38700 lbf
  • Static Radial Load 46200 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 10000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 5090 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 3.600 lb

Features

Performance Features of 536-534 Bearing

536-534 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 38,700 lbf, ensuring reliable performance in heavy-duty applications.

The steel cage maintains proper roller alignment, reducing friction and extending service life.
With a temperature range of -30° to 110°C, it performs well in various operating conditions.

536-534 Bearing’s standard radial clearance provides flexibility for different installation needs.
Its ABEC-1 rating ensures consistent precision for industrial applications.

Application

Industrial Uses of 536-534 Bearing
536-534 Bearing is commonly used in heavy machinery like construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability even in tough working conditions.

In automotive applications, 536-534 Bearing fits well in wheel hubs and differential systems, providing reliable performance under both radial and thrust loads. Its inch sizing makes it a preferred choice for American and British vehicle models.

For industrial conveyor systems, 536-534 Bearing’s open design allows for easy lubrication, extending its service life in high-load scenarios. The steel cage adds extra strength, making it suitable for continuous operation.

Where Is 536-534 Bearing Used?
536-534 Bearing finds its place in mining equipment, where its robust design withstands harsh environments. The standard radial clearance ensures smooth operation even with varying loads.

In power transmission systems, 536-534 Bearing supports shafts and gears, offering stability under dynamic conditions. Its ABEC-1 rating provides a balance of precision and affordability for general industrial use.

Built for Heavy-Duty Use: 536-534 Bearing
536-534 Bearing excels in applications like forklifts and cranes, where its high static radial load capacity is crucial. The tapered rollers distribute stress evenly, reducing wear over time.

For railway applications, 536-534 Bearing’s temperature range makes it reliable in varying climates. Its compatibility with Timken models adds to its versatility across different machinery types.

Automotive vs Aerospace: Applications of 536-534 Bearing
In automotive systems, 536-534 Bearing is ideal for drivetrains, handling both speed and load demands. The inch measurements ensure easy integration into existing designs.

For aerospace ground equipment, 536-534 Bearing provides dependable performance in auxiliary systems. Its chrome steel components resist corrosion, even in demanding environments.
