Thin Section Ball Bearings S6700zz

Thin Section Ball Bearings S6700zz

The S6700zz is a compact thin-section ball bearing, measuring just 10mm by 15mm by 4mm, crafted entirely from stainless steel for durability. It handles radial loads up to 173 lbf and spins smoothly at speeds up to 13,500 RPM.

Its shielded design keeps out dust and debris, while the stainless steel cage ensures reliable performance. The bearing operates in temperatures from -86°F to 230°F, making it versatile for various environments.

With ABEC-1 precision and C0 radial clearance, it offers consistent performance for light to moderate loads. Ideal for small machinery, medical devices, or precision instruments where space is limited.

Weighing only 1.9g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a safe choice for many applications. Regular lubrication is recommended for optimal performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S6700zz
  • Brand TFL
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 15 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 173 lbf
  • Static Radial Load 88 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13500 rpm
  • Weight 1.9 g
  • Price（$） 1.2
Thin Section Ball Bearings S6700zz dimension drawing
Download DWG Download PDF

Features

Performance Features of S6700zz Bearing

S6700zz Bearing is crafted with stainless steel rings and balls, offering reliable radial load support.
Its compact size of 10 mm×15 mm×4 mm makes it ideal for space-constrained applications.

The shielded design protects against contaminants while maintaining smooth operation.
With a maximum speed of 13,500 rpm, it ensures efficient performance in various conditions.

S6700zz Bearing operates in a wide temperature range from -86 to 230 °F.
Its stainless steel construction provides good resistance to corrosion and wear.

Application

Industrial Uses of S6700zz Bearing
S6700zz Bearing is commonly used in compact machinery where space is limited, such as small gearboxes and precision instruments. Its thin section design and stainless steel construction make it suitable for environments requiring corrosion resistance.

Where Is S6700zz Bearing Used?
You’ll often find S6700zz Bearing in medical devices like dental drills and lab equipment, where its small size and reliability are key. The shielded design helps keep contaminants out, ensuring smooth operation.

Built for Heavy-Duty Use: S6700zz Bearing
Despite its slim profile, S6700zz Bearing handles radial loads well in applications like robotic arms and 3D printers. The ABEC-1 tolerance ensures consistent performance without needing frequent adjustments.

Automotive vs Aerospace: Applications of S6700zz Bearing
In automotive systems, S6700zz Bearing fits well in sensors and small actuators due to its lightweight design. For aerospace, it’s used in navigation equipment where precision and durability matter most.

Perfect Fit for Automation: S6700zz Bearing
S6700zz Bearing works smoothly in automated conveyor systems and packaging machines. Its low friction and high-speed capability make it a reliable choice for continuous operation.
