Stainless Steel Deep Groove Ball Bearings W 605

Stainless Steel Deep Groove Ball Bearings W 605

The W 605 is a compact stainless steel deep groove ball bearing, measuring just 5mm by 14mm by 5mm. Its open design and single-row construction make it easy to handle radial loads up to 171 lbf.

This bearing spins smoothly at speeds up to 67,000 RPM, thanks to its stainless steel balls and cage. It performs reliably in temperatures ranging from -30°C to 120°C.

With a P0 tolerance class and CN radial clearance, it offers consistent performance for precision applications. The all-stainless construction resists corrosion, ideal for damp or harsh environments.

Weighing only 0.0031 kg, it’s a lightweight choice for small machinery, medical devices, or food processing equipment. Compliant with RoHS and REACH standards, it’s a safe and versatile option.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 605
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 5 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 14 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 5 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 171 lbf
  • Static Radial Load 58 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 67000 rpm
  • Weight 0.0031 kg
Stainless Steel Deep Groove Ball Bearings W 605 dimension drawing
Download DWG Download PDF

Features

Why Choose W 605 Bearing for Precision Tasks?

W 605 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its compact size of 5 mm×14 mm×5 mm makes it ideal for applications where space is limited.

The single-row design ensures smooth radial load handling, with a dynamic radial load capacity of 171 lbf.
With a maximum speed of 67,000 rpm, it delivers reliable performance in high-speed environments.

W 605 Bearing operates efficiently in temperatures ranging from -30° to 120 °C.
Its open seal type allows for easy lubrication, though it comes pre-lubricated for immediate use.

Application

Common Applications of W 605 Bearing
W 605 Bearing is widely used in small electric motors, such as those found in household appliances or office equipment. Its compact size and stainless steel construction make it resistant to corrosion, ideal for humid environments.

How Does W 605 Bearing Improve Performance?
In precision instruments like dental drills or laboratory scales, W 605 Bearing ensures smooth rotation with minimal friction. The open design allows for easy cleaning, which is essential in medical and scientific settings.

Built for Heavy-Duty Use: W 605 Bearing
Despite its small size, W 605 Bearing handles radial loads effectively in conveyor systems or packaging machinery. The stainless steel materials provide durability even in demanding industrial conditions.

Automotive vs Aerospace: Applications of W 605 Bearing
In automotive applications, W 605 Bearing is often found in dashboard controls or window regulators. For aerospace, its lightweight design suits small actuators or instrumentation panels where space is limited.

Perfect Fit for Automation: W 605 Bearing
W 605 Bearing works well in robotic arms or 3D printers, offering reliable performance in repetitive motions. The high-speed capability ensures efficiency in automated production lines.
