Stainless Steel Deep Groove Ball Bearings W 602

Stainless Steel Deep Groove Ball Bearings W 602

The W 602 is a compact stainless steel deep groove ball bearing, measuring just 2mm by 7mm by 2.8mm. It handles radial loads up to 50 lbf and spins smoothly at speeds up to 100,000 RPM.

Its open design and stainless steel construction make it resistant to corrosion, while the single-row design ensures reliable performance. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a convenient replacement option. Ideal for small devices like precision instruments or miniature motors where space is limited.

Weighing only 0.0005kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 602
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 2 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 7 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 2.8 mm
  • Width Tolerance -0.04mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 50 lbf
  • Static Radial Load 15 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 100000 rpm
  • Weight 0.0005 kg
Stainless Steel Deep Groove Ball Bearings W 602 dimension drawing
Download DWG Download PDF

Features

Why Choose W 602 Bearing for Precision Tasks?

W 602 Bearing is crafted from stainless steel, ensuring resistance to corrosion and wear.
Its compact size of 2 mm×7 mm×2.8 mm makes it ideal for applications requiring precision and space efficiency.
The open design allows for easy lubrication, maintaining smooth operation even at high speeds.
With a maximum speed of 100,000 rpm, it delivers reliable performance in demanding conditions.

Application

Common Applications of W 602 Bearing
W 602 Bearing is widely used in small precision instruments, such as watches and miniature motors, where its compact size and stainless steel construction ensure reliable performance. The open design allows for easy cleaning, making it suitable for environments where hygiene is important.

In consumer electronics, W 602 Bearing can be found in devices like small fans and printers, providing smooth rotation with minimal noise. Its high-speed capability makes it a dependable choice for applications requiring consistent, long-term operation.

For medical devices, W 602 Bearing’s stainless steel material offers excellent resistance to corrosion, ideal for surgical tools and diagnostic equipment. The lightweight design also helps reduce the overall weight of portable medical instruments.

Automation systems benefit from W 602 Bearing in components like robotic arms and 3D printers, where precision and durability are key. Its metric sizing ensures compatibility with a variety of international machinery standards.
