Stainless Steel Deep Groove Ball Bearings W 6000

Stainless Steel Deep Groove Ball Bearings W 6000

The W 6000 is a compact stainless steel deep groove ball bearing, measuring 10mm by 26mm by 8mm. It handles radial loads up to 892 lbf and can spin at speeds up to 40,000 RPM, making it suitable for fast-moving applications.

Made entirely from stainless steel, it resists corrosion and works well in temperatures from -30°C to 120°C. Its open design allows for easy lubrication and maintenance.

This bearing is interchangeable with SKF models, offering a reliable replacement option. Ideal for use in food processing equipment or marine environments where rust resistance is key.

Weighing just 0.017kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6000
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 26 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 892 lbf
  • Static Radial Load 441 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 40000 rpm
  • Weight 0.017 kg
Stainless Steel Deep Groove Ball Bearings W 6000 dimension drawing
Download DWG Download PDF

Features

Why Choose W 6000 Bearing for Precision Tasks?

W 6000 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its single-row design ensures smooth radial load handling, with a dynamic capacity of 892 lbf.

The open seal type allows for easy maintenance, while the P0 tolerance class guarantees precision.
With a maximum speed of 40,000 rpm, it is ideal for high-speed applications.

Stainless steel components ensure durability, even in challenging environments.
Its compact size (10 mm×26 mm×8 mm) makes it suitable for space-constrained installations.

Application

Industrial Uses of W 6000 Bearing
W 6000 Bearing is commonly used in industrial equipment like small pumps and electric motors, where its stainless steel construction resists corrosion. The open design allows for easy lubrication, extending service life in dusty or humid conditions.

Where Is W 6000 Bearing Used?
In automotive applications, W 6000 Bearing fits well in components like alternators and small gearboxes, thanks to its compact size and radial load capacity. Its metric dimensions make it a versatile choice for various vehicle models.

Perfect Fit for Automation: W 6000 Bearing
For robotics and automation, W 6000 Bearing ensures smooth movement in joints and small actuators. The stainless steel balls and rings provide reliable performance even with frequent direction changes.

Medical vs Industrial: Where W 6000 Bearing Excels
In medical devices, W 6000 Bearing is ideal for precision instruments like dental tools, where hygiene and durability matter. Its industrial strength also makes it suitable for food processing equipment.

Designed for Versatility: W 6000 Bearing
W 6000 Bearing works well in household appliances like blenders and fans, offering quiet operation and long-lasting performance. The stainless steel materials prevent rust, even in damp environments.
