Snap Ring Groove Ball Bearings 6013-ZNR ARMOR GUARD

Snap Ring Groove Ball Bearings 6013-ZNR ARMOR GUARD

The 6013-ZNR ARMOR GUARD is a shielded ball bearing with a 65mm bore and 100mm outer diameter, built from sturdy chrome steel. It handles radial loads up to 6857 lbf and operates smoothly at speeds up to 6700 RPM.

Its snap ring groove on the outer ring ensures secure fitting, while the shielded design keeps contaminants out for longer service life. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery where radial loads and secure mounting are key, such as electric motors or conveyor systems.

Weighing 430g, it offers a good balance of strength and compactness. Compliant with RoHS and REACH standards for safe industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6013-ZNR ARMOR GUARD
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Outside Diameter Of Snap Ring 106.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 6857 lbf
  • Static Radial Load 5665 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 430 g
  • Price（$） 19.74
Snap Ring Groove Ball Bearings 6013-ZNR ARMOR GUARD dimension drawing
Download DWG Download PDF

Features

How Does 6013-ZNR ARMOR GUARD Bearing Resist Wear?

6013-ZNR ARMOR GUARD Bearing is built with chrome steel rings and balls, offering strong resistance to wear in radial load applications.
Its dynamic radial load capacity reaches 6857 lbf, ensuring reliable performance under stress.

The shielded design protects against contaminants, extending the bearing’s service life.
With a maximum speed of 6,700 rpm, it balances durability and smooth operation.

The snap ring groove ensures secure fitting, reducing movement and further wear.
Its temperature range of -30° to 120°C makes it suitable for various environments.

Application

Common Applications of 6013-ZNR ARMOR GUARD Bearing
6013-ZNR ARMOR GUARD Bearing is widely used in industrial equipment like conveyor systems and electric motors, where its shielded design helps keep out contaminants. The snap ring feature ensures secure mounting, reducing the risk of slippage during operation.

How Does 6013-ZNR ARMOR GUARD Bearing Improve Performance?
In automotive applications such as wheel hubs and transmissions, 6013-ZNR ARMOR GUARD Bearing offers reliable radial load support. Its chrome steel construction provides durability, even under high-speed conditions.

Built for Heavy-Duty Use: 6013-ZNR ARMOR GUARD Bearing
6013-ZNR ARMOR GUARD Bearing is a solid choice for machinery requiring consistent performance, like pumps and gearboxes. The ABEC 1 tolerance ensures smooth operation without excessive vibration.

Medical vs Industrial: Where 6013-ZNR ARMOR GUARD Bearing Excels
While 6013-ZNR ARMOR GUARD Bearing is common in industrial settings, its precision also suits medical devices like lab equipment. The shielded design helps maintain cleanliness in sensitive environments.

Perfect Fit for Automation: 6013-ZNR ARMOR GUARD Bearing
In robotic arms and automated assembly lines, 6013-ZNR ARMOR GUARD Bearing provides stable rotation. Its snap ring groove simplifies installation, saving time during maintenance.
