Snap Ring Groove Ball Bearings 6013-2RS1NR/C3W64

Snap Ring Groove Ball Bearings 6013-2RS1NR/C3W64

The 6013-2RS1NR/C3W64 is a sealed snap ring groove ball bearing with a 65mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 6857 lbf and operates smoothly at speeds up to 6700 RPM.

Its sealed design keeps dirt out and solid oil lubrication ensures long-lasting performance without frequent maintenance. The snap ring feature on the outer ring makes installation secure and straightforward.

With a C3 radial clearance, it accommodates slight misalignments and thermal expansion. Ideal for industrial machinery, electric motors, or pumps where reliability is key.

Weighing 430g, it’s robust yet manageable. Compliant with RoHS and REACH standards, it’s safe for various applications in temperatures from -30°C to 120°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6013-2RS1NR/C3W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Outside Diameter Of Snap Ring 106.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 6857 lbf
  • Static Radial Load 5665 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 430 g
Snap Ring Groove Ball Bearings 6013-2RS1NR/C3W64 dimension drawing
Download DWG Download PDF

Features

How Is 6013-2RS1NR/C3W64 Bearing Engineered for Reliability?

6013-2RS1NR/C3W64 Bearing features sealed construction, protecting against dust and moisture for consistent performance.

Its chrome steel rings and balls provide strong resistance to wear, ensuring durability in radial load applications.

With a dynamic radial load capacity of 6857 lbf, it handles demanding conditions while maintaining smooth operation.

The snap ring design simplifies installation, making it a practical choice for various industrial uses.

Application

Industrial Uses of 6013-2RS1NR/C3W64 Bearing
6013-2RS1NR/C3W64 Bearing is commonly used in industrial machinery, such as conveyor systems and electric motors, where its sealed design helps keep out dust and debris. The snap ring feature ensures easy installation and secure positioning in housings.

In automotive applications, 6013-2RS1NR/C3W64 Bearing can be found in components like alternators and water pumps, providing reliable radial load support. Its solid oil lubrication extends service life, even under continuous operation.

For automation equipment, 6013-2RS1NR/C3W64 Bearing offers smooth performance in robotic arms and linear guides. The C3 radial clearance allows for slight misalignments without compromising efficiency.

In household appliances like washing machines, 6013-2RS1NR/C3W64 Bearing’s durability and low maintenance make it a practical choice. The chrome steel construction resists wear, ensuring long-term reliability.
