Single Row Deep Groove Ball Bearings ICOS-D1B04 TN9

The ICOS-D1B04 TN9 is a single row deep groove ball bearing with a 20mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3035 lbf and can spin at speeds reaching 9300 RPM.

Its open design simplifies maintenance, while the nylon cage reduces friction for smoother operation. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical alternative for replacements. Suitable for applications like electric motors or small machinery where radial loads are typical.

Weighing only 0.11kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number ICOS-D1B04 TN9
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class P6
Radial Clearance Trade No CN
Bore Dia 20 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 47 mm
Outer Dia Tolerance -0.009mm to 0
Width 14 mm
Width Tolerance -0.12mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Nylon
REACH Compliant
Temperature Range -30° to 120 °C
Dynamic Radial Load 3035 lbf
Static Radial Load 1472 lbf
Max Speed 9300 rpm
Weight 0.11 kg

Single Row Deep Groove Ball Bearings ICOS-D1B04 TN9 dimension drawing

Download DWG Download PDF

Features

Performance Features of ICOS-D1B04 TN9 Bearing

ICOS-D1B04 TN9 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3035 lbf, ensuring reliable performance in various applications.

The nylon cage keeps the balls aligned, reducing friction and extending service life.
With a maximum speed of 9,300 rpm, it balances durability and efficiency.

ICOS-D1B04 TN9 Bearing operates smoothly in temperatures ranging from -30° to 120°C.
Its open design simplifies maintenance, making it a practical choice for many uses.

Application

Industrial Uses of ICOS-D1B04 TN9 Bearing
ICOS-D1B04 TN9 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design and P6 tolerance make it suitable for precision applications.

What Makes ICOS-D1B04 TN9 Bearing a Preferred Choice?
In automotive applications, ICOS-D1B04 TN9 Bearing fits well in alternators and small gearboxes due to its compact size and high-speed capability. The chrome steel construction offers durability under continuous use.

Perfect Fit for Automation: ICOS-D1B04 TN9 Bearing
For robotics and automation, ICOS-D1B04 TN9 Bearing provides smooth operation in joints and linear guides. Its nylon cage reduces friction, making it ideal for repetitive movements.

Medical vs Industrial: Where ICOS-D1B04 TN9 Bearing Excels
In medical devices, ICOS-D1B04 TN9 Bearing is used in lab equipment for its precision and cleanliness. Meanwhile, in industrial settings, it handles moderate loads in conveyor systems effectively.

Light-Duty vs Heavy-Duty: Best Uses for ICOS-D1B04 TN9 Bearing
For light-duty tasks like office printers, ICOS-D1B04 TN9 Bearing ensures quiet operation. In heavier applications, it supports radial loads in small machinery without compromising performance.
