Single Row Deep Groove Ball Bearings 6213/VW538

Single Row Deep Groove Ball Bearings 6213/VW538

The 6213/VW538 is a single-row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 12859 lbf and operates smoothly at speeds up to 5300 RPM.
Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for radial load applications like electric motors or pumps.
Weighing 979g, it balances strength and lightness. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6213/VW538
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12859 lbf
  • Static Radial Load 9015 lbf
  • Max Speed 5300 rpm
  • Weight 979 g
Single Row Deep Groove Ball Bearings 6213/VW538 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6213/VW538 Bearing

6213/VW538 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 12859 lbf.

Its open design allows for easy lubrication and maintenance, ensuring smooth operation in various conditions.

The ABEC 1 tolerance class ensures reliable performance, making it suitable for general industrial applications.

With a maximum speed of 5,300 rpm, it balances durability and efficiency for long-term use.

Application

Industrial Uses of 6213/VW538 Bearing
The 6213/VW538 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open seal type allows for easy lubrication, extending service life in demanding conditions.

What Makes 6213/VW538 Bearing a Preferred Choice?
In automotive applications, 6213/VW538 Bearing fits well in wheel hubs and alternators due to its balanced load capacity and smooth operation. The chrome steel construction ensures durability even under continuous use.

Perfect Fit for Automation: 6213/VW538 Bearing
For automated systems, 6213/VW538 Bearing works reliably in conveyor belts and robotic arms, thanks to its precise tolerance class. The metric dimensions make it compatible with a variety of European machinery standards.

Medical vs Industrial: Where 6213/VW538 Bearing Excels
While 6213/VW538 Bearing performs well in industrial settings, it also suits medical devices like centrifuges, where consistent rotation is key. The temperature range ensures stability in both sterile and high-heat environments.
