Single Row Cylindrical Roller Thrust Bearings 81207 TN

Single Row Cylindrical Roller Thrust Bearings 81207 TN

The 81207 TN is a single-row cylindrical roller thrust bearing with a 35mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages thrust loads up to 13950 lbf and operates smoothly at speeds up to 4000 RPM.

Its glass fibre reinforced PA66 cage offers durability and reduces friction, while the chrome steel rollers ensure reliable performance. The bearing functions well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like heavy machinery or industrial equipment where high thrust loads are expected.

Weighing just 0.21kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 81207 TN
  • size 35 mm x 62 mm x 18 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 1
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.019mm to 0
  • Width 18 mm
  • Height Tolerance -0.25mm to +0.02mm
  • Outside Diameter Shaft Washer 62 mm
  • Bore Diameter Housing Washer 37 mm
  • Height Shaft Washer 5.25 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 1 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 13950 lbf
  • Static Radial Load 42750 lbf
  • Max Speed 4000 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.21 kg
  • Roller And Cage Thrust Assembly K 81207 TN
  • Shaft Washer WS 81207
  • Housing Washer GS 81207
Single Row Cylindrical Roller Thrust Bearings 81207 TN dimension drawing
Download DWG Download PDF

Features

Performance Features of 81207 TN Bearing

81207 TN Bearing is crafted with chrome steel washers and rollers, offering robust resistance to thrust loads.
Its dynamic radial load capacity reaches 13950 lbf, making it suitable for heavy-duty applications.

The glass fibre reinforced PA66 cage ensures smooth operation and reduces wear over time.
With a maximum speed of 4000 rpm, it delivers reliable performance in various conditions.

Designed for temperatures from -30° to 110°C, 81207 TN Bearing adapts well to different environments.
Its precise dimensions and tolerances ensure easy installation and consistent performance.

Application

Industrial Uses of 81207 TN Bearing
81207 TN Bearing is commonly used in heavy machinery like hydraulic presses and gearboxes, where its cylindrical roller design handles high thrust loads efficiently. The glass fibre reinforced cage ensures durability even in demanding industrial environments.

What Makes 81207 TN Bearing a Preferred Choice?
In automotive applications, 81207 TN Bearing fits well in transmission systems, providing reliable performance under constant axial forces. Its metric sizing makes it a versatile option for various vehicle models.

Built for Heavy-Duty Use: 81207 TN Bearing
For automation equipment, 81207 TN Bearing supports robotic arms and conveyor systems, thanks to its high dynamic load capacity. The chrome steel construction ensures long service life in continuous operation.

Medical vs Industrial: Where 81207 TN Bearing Excels
While not typically used in medical devices, 81207 TN Bearing shines in industrial settings like packaging machines. Its temperature range and load capacity make it suitable for high-intensity tasks.

Practical Applications of 81207 TN Bearing
In consumer electronics, 81207 TN Bearing can be found in heavy-duty printers and industrial fans. The PA66 cage material reduces friction, ensuring smooth operation over time.
