LM814845 Single Cones (Imperial)

LM814845 Single Cones (Imperial)

The LM814845 is a single-row tapered roller bearing with a 2.875-inch bore, designed for combined loads. Made from durable chrome steel, it handles dynamic radial loads up to 26,500 lbf and static radial loads up to 41,200 lbf.

Its open design allows for easy maintenance, while the steel cage ensures reliable performance. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or vehicle axles where combined loads are common.

Compliant with RoHS and REACH standards, it offers a balance of strength and durability. The standard radial clearance can also be adjusted to C3, C4, or C5 as needed.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number LM814845
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Inch
  • Type Cones
  • Bearing Part Number LM814845-LM814810 , LM814845-LM814810-B
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Series LM814800
  • Bore Dia 2.875"
  • Bore Dia Tolerance +0.005" to 0
  • Cone Width 1"
  • Cone Width Tolerance +0.003" to -0.01
  • Cone Backface ToClear Radius 0.14"
  • Cone Frontface Backing Diameter 3.19"
  • Cone Backface Backing Diameter 3.43"
  • Cage Cone Frontface Clearance 0.09"
  • Cage Cone Backface Clearance 0.08"
  • Effective Center Location 0.09"
  • Ring Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 26500 lbf
  • Static Radial Load 41200 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 6870 lbf
  • Dynamic Radial Rating(Two Row 1 Million Revolutions)(C1) 46100 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 5990 lbf
  • Dynamic Radial Rating(Two Row 90 Million Revolutions)(C90) 12000 lbf
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant

Features

Performance Features of LM814845 Bearing

LM814845 Bearing is crafted from chrome steel, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 26,500 lbf, ensuring reliable performance in tough conditions.

The tapered roller design enhances efficiency, making it suitable for various industrial applications.
With a temperature range of -30° to 110°C, it performs well in diverse environments.

LM814845 Bearing’s steel cage maintains roller alignment, reducing wear and extending lifespan.
Its standard radial clearance options provide flexibility for different operational needs.

The ABEC-1 rating ensures consistent precision, while the open seal design simplifies maintenance.
This bearing is interchangeable with Timken models, offering convenient replacement options.

Application

Industrial Uses of LM814845 Bearing
LM814845 Bearing is commonly used in heavy machinery, such as construction equipment and mining tools, where its tapered roller design handles combined loads effectively. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

Where Is LM814845 Bearing Used?
You’ll find LM814845 Bearing in automotive applications like truck wheel hubs, where its chrome steel construction ensures durability under heavy radial and thrust loads. Its inch sizing makes it a fit for older or imperial-based machinery.

Built for Heavy-Duty Use: LM814845 Bearing
LM814845 Bearing excels in industrial gearboxes, providing reliable performance even under high dynamic loads. The steel cage adds strength, making it suitable for continuous operation in harsh environments.

Automotive vs Aerospace: Applications of LM814845 Bearing
In automotive settings, LM814845 Bearing supports axle systems, while its precision makes it adaptable for aerospace ground equipment. The ABEC-1 rating ensures consistent performance across different applications.

Key Fields for LM814845 Bearing
LM814845 Bearing is ideal for agricultural machinery, such as tractors, where its tapered rollers manage uneven loads. The standard radial clearance offers flexibility for various operational needs.
