LM565943 Single Cones (Imperial)

LM565943 Single Cones (Imperial)

The LM565943 is a single-row tapered roller bearing cone with a 14.75-inch bore, designed for combined loads. Made from sturdy chrome steel, it handles dynamic radial loads up to 313,000 lbf and static loads up to 663,000 lbf.

Its open design allows for easy maintenance, while the steel cage ensures durability. The cone has a width of 3.3125 inches and operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or large vehicles where robust performance is needed.

Compliant with RoHS and REACH standards, it offers reliable and safe operation. The standard radial clearance can also be adjusted to C3, C4, or C5 for specific needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number LM565943
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Inch
  • Type Cones
  • Bearing Part Number LM565943-LM565910
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Series LM565900
  • Bore Dia 14.75"
  • Bore Dia Tolerance +0.001" to 0
  • Cone Width 3.3125"
  • Cone Width Tolerance +0.003" to -0.01
  • Cone Backface ToClear Radius 0.25"
  • Cone Frontface Backing Diameter 15.63"
  • Cone Backface Backing Diameter 16.02"
  • Cage Cone Frontface Clearance 0.19"
  • Cage Cone Backface Clearance 0.44"
  • Effective Center Location 0.35"
  • Ring Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 313000 lbf
  • Static Radial Load 663000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 81000 lbf
  • Dynamic Radial Rating(Two Row 1 Million Revolutions)(C1) 544000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 53500 lbf
  • Dynamic Radial Rating(Two Row 90 Million Revolutions)(C90) 141000 lbf
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant

Features

Performance Features of LM565943 Bearing

LM565943 Bearing is crafted from chrome steel, offering robust resistance to combined loads with a dynamic radial load capacity of 313,000 lbf.
Its tapered roller design ensures efficient load distribution, enhancing durability in demanding applications.

The steel cage maintains proper roller alignment, reducing friction and extending the bearing’s service life.
With a temperature range of -30° to 110°C, LM565943 Bearing performs reliably in various environments.

LM565943 Bearing’s standard radial clearance and ABEC-1 rating provide consistent performance for industrial use.
Its open seal design allows for easy inspection and maintenance, keeping operational costs low.

Application

Industrial Uses of LM565943 Bearing
LM565943 Bearing is commonly used in heavy machinery, such as mining equipment and construction vehicles, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability in demanding environments.

Where Is LM565943 Bearing Used?
You’ll often find LM565943 Bearing in agricultural machinery, supporting components like gearboxes and axles. Its inch sizing makes it a reliable choice for older or imperial-based systems.

Built for Heavy-Duty Use: LM565943 Bearing
LM565943 Bearing excels in industrial fans and pumps, where its open design allows for easy lubrication and maintenance. The steel cage adds extra strength for long-term performance.

Automotive vs Aerospace: Applications of LM565943 Bearing
In automotive settings, LM565943 Bearing is ideal for wheel hubs and differentials, while its high load capacity also suits aerospace landing gear systems. The ABEC-1 rating ensures consistent precision.

Key Fields for LM565943 Bearing
LM565943 Bearing is a go-to for railway applications, particularly in freight car axles, thanks to its dynamic radial load capacity. The standard radial clearance offers flexibility for various operational needs.
