Heavy Duty Needle Roller Bearings (Machined) NKI7/12-TV-XL

Heavy Duty Needle Roller Bearings (Machined) NKI7/12-TV-XL

The NKI7/12-TV-XL is a heavy-duty needle roller bearing with a 7mm bore and 17mm outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1192 lbf and spins at speeds up to 29,500 RPM, making it suitable for high-speed applications.

Its open design and PA66 cage ensure smooth operation, while the press-fit shaft mount provides a secure installation. The bearing requires regular lubrication to maintain optimal performance.

This model is interchangeable with INA bearings, offering flexibility for replacements. Ideal for use in compact machinery or automotive components where space is limited but durability is key.

Weighing just 13.7g, it’s lightweight yet robust. Compliant with RoHS standards, it operates efficiently in temperatures from -20°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NKI7/12-TV-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Inner Ring Yes
  • Series With Inner Ring
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 17 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 12 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Steel
  • Cage Material PA66
  • Roller Material Steel
  • Dynamic Radial Load 1192 lbf
  • Static Radial Load 1238 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 29500 rpm
  • Weight 13.7 g
Heavy Duty Needle Roller Bearings (Machined) NKI7/12-TV-XL dimension drawing
Download DWG Download PDF

Features

How Does NKI7/12-TV-XL Bearing Handle High-Speed Applications?
NKI7/12-TV-XL Bearing is built with steel rollers and rings, offering robust radial load capacity up to 1192 lbf.
Its PA66 cage ensures smooth operation at speeds up to 29,500 rpm, making it ideal for high-speed machinery.
The press-fit shaft mount design simplifies installation, saving time and effort.
With a temperature range of -20 to 110°C, it performs reliably in various environments.

Application

Industrial Uses of NKI7/12-TV-XL Bearing
NKI7/12-TV-XL Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, like conveyor systems and packaging equipment. Its steel construction ensures durability in demanding environments.
Where Is NKI7/12-TV-XL Bearing Used?
In automotive applications, NKI7/12-TV-XL Bearing fits well in gearboxes and transmission systems, providing reliable performance under high-speed conditions. The press-fit design makes installation straightforward for mechanics.
Built for Heavy-Duty Use: NKI7/12-TV-XL Bearing
For automation and robotics, NKI7/12-TV-XL Bearing offers smooth operation in robotic arms and linear guides. The open seal type allows for easy lubrication, extending its service life.
Automotive vs Industrial: Applications of NKI7/12-TV-XL Bearing
In consumer electronics, NKI7/12-TV-XL Bearing can be found in printers and small appliances, where its compact size and efficiency are beneficial. The PA66 cage material reduces friction for quieter operation.
