Flanged Deep Groove Ball Bearings D/W R6 R-2RS1

Flanged Deep Groove Ball Bearings D/W R6 R-2RS1

The D/W R6 R-2RS1 is a compact flanged deep groove ball bearing, measuring 0.375″ in bore and 0.875″ in outer diameter. Made entirely from stainless steel, it offers good corrosion resistance and durability.

This sealed bearing handles radial loads up to 555 lbf and can spin at speeds up to 20,000 RPM. Its grease lubrication ensures smooth operation with minimal maintenance required.

The built-in flange provides secure mounting, while the sealed design keeps contaminants out. It performs reliably in temperatures from -30°C to 120°C.

Ideal for small machinery or appliances where space is limited. With a lightweight design at just 0.012kg, it’s easy to handle and install. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R6 R-2RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 0.375"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.875"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.28118"
  • Width Tolerance -0.005" to 0"
  • Flange Outer Dia 0.96902"
  • Flange Thickness 0.06201"
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 555 lbf
  • Static Radial Load 252 lbf
  • Max Speed 20000 rpm
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.012 kg
  • Price（$） 1.3
Flanged Deep Groove Ball Bearings D/W R6 R-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R6 R-2RS1 Bearing for Precision Tasks?

D/W R6 R-2RS1 Bearing features a sealed design, protecting it from dust and moisture for consistent performance.
Its stainless steel construction ensures corrosion resistance, making it suitable for various environments.
The flanged outer ring provides secure mounting, reducing misalignment risks during operation.
With a maximum speed of 20,000 rpm, it delivers smooth and efficient performance in precision applications.

Application

Common Applications of D/W R6 R-2RS1 Bearing
D/W R6 R-2RS1 Bearing is widely used in industrial equipment, especially in conveyor systems and small machinery where its sealed design keeps contaminants out. The stainless steel construction ensures durability in demanding environments.

In automotive applications, D/W R6 R-2RS1 Bearing fits well in electric motors and small gearboxes, providing reliable radial load support. Its inch sizing makes it compatible with many North American vehicle components.

For home appliances like fans and printers, D/W R6 R-2RS1 Bearing offers smooth operation with minimal maintenance. The grease lubrication and sealed design extend its lifespan in everyday use.

Automation systems benefit from D/W R6 R-2RS1 Bearing’s precision and flange design, which simplifies installation in robotic arms and 3D printers. The high-speed capability ensures consistent performance in repetitive tasks.
