Drawn Cup Needle Roller Bearings SCE48-P

Drawn Cup Needle Roller Bearings SCE48-P

The SCE48-P is a compact drawn cup needle roller bearing with a 0.25″ bore and 0.4375″ outer diameter, crafted from sturdy steel. It handles radial loads up to 922 lbf and spins efficiently at speeds up to 35,000 RPM.
Its single-seal design helps keep contaminants out while maintaining smooth operation. The press-fit mounting ensures a secure attachment to shafts.
This bearing is ideal for high-speed applications like small engines or power tools where space is limited. It requires regular lubrication for optimal performance.
Interchangeable with INA bearings, it offers a reliable replacement option. Suitable for temperatures ranging from -20°C to 110°C.
Weighing very little, it’s a practical choice for lightweight machinery. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE48-P
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.25"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 0.4375"
  • Outer Dia Tolerance Not Rated
  • Width 0.5"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Single Seal
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 922 lbf
  • Static Radial Load 877 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 35000 rpm
  • Weight 4 g
Drawn Cup Needle Roller Bearings SCE48-P dimension drawing
Download DWG Download PDF

Features

How Does SCE48-P Bearing Handle High-Speed Applications?
SCE48-P Bearing is crafted with steel rings and needles, offering robust radial load support up to 922 lbf.
Its press-fit shaft mount ensures secure installation, reducing slippage during high-speed operation.
The single-seal design helps retain lubrication, maintaining smooth performance at speeds up to 35,000 rpm.
With a temperature range of -20 to 110°C, it adapts well to various operating conditions.

Application

Industrial Uses of SCE48-P Bearing
SCE48-P Bearing is commonly used in industrial gearboxes, where its compact design and high radial load capacity make it ideal for tight spaces. The steel construction ensures durability even in demanding environments.
Where Is SCE48-P Bearing Used?
You’ll often find SCE48-P Bearing in automotive transmissions, providing smooth operation under high-speed conditions. Its press-fit design simplifies installation, saving time during assembly.
Perfect Fit for Automation: SCE48-P Bearing
In robotic arms, SCE48-P Bearing offers reliable performance with minimal maintenance. The single seal helps keep contaminants out, extending the bearing’s lifespan.
Light-Duty vs Heavy-Duty: Best Uses for SCE48-P Bearing
For light-duty applications like small electric motors, SCE48-P Bearing delivers consistent performance. In heavier setups, it handles radial loads efficiently without compromising speed.
Medical vs Industrial: Where SCE48-P Bearing Excels
While SCE48-P Bearing isn’t typically used in medical devices, it shines in industrial settings like conveyor systems. Its high-speed capability and steel construction make it a dependable choice.
