Stainless Steel Deep Groove Ball Bearings W 61909-2RS1

Stainless Steel Deep Groove Ball Bearings W 61909-2RS1

The W 61909-2RS1 is a stainless steel deep groove ball bearing with a 45mm bore and 68mm outer diameter, measuring 12mm wide. Its sealed design keeps grease in and dirt out, making it low-maintenance.

This bearing handles radial loads up to 2720 lbf and spins smoothly at 6000 RPM. The all-stainless construction resists corrosion and works in temperatures from -30°C to 120°C.

Its compact size and sealed protection make it ideal for food processing equipment or marine applications where moisture is present. The bearing is interchangeable with SKF models for easy replacement.

Weighing just 0.13kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61909-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 68 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 12 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 2720 lbf
  • Static Radial Load 2428 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 0.13 kg
  • Price（$） 53.51
Stainless Steel Deep Groove Ball Bearings W 61909-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 61909-2RS1 Bearing for Precision Tasks?

W 61909-2RS1 Bearing is crafted with stainless steel rings and balls, offering excellent resistance to corrosion and wear.
Its sealed design keeps out contaminants, ensuring smooth operation in various environments.

The bearing handles dynamic radial loads up to 2720 lbf, making it suitable for demanding applications.
With a maximum speed of 6,000 rpm, it delivers reliable performance without compromising efficiency.

W 61909-2RS1 Bearing’s grease lubrication reduces maintenance needs, extending its service life.
Its compact size (45 mm×68 mm×12 mm) makes it ideal for space-constrained installations.

Application

Industrial Uses of W 61909-2RS1 Bearing
W 61909-2RS1 Bearing is commonly used in industrial machinery like pumps and compressors, where its sealed design keeps contaminants out. The stainless steel construction ensures it performs well in wet or corrosive environments.

What Makes W 61909-2RS1 Bearing a Preferred Choice?
In automotive applications, W 61909-2RS1 Bearing fits well in electric motors and alternators, offering reliable radial load support. Its grease lubrication reduces maintenance needs, making it a hassle-free option for long-term use.

Perfect Fit for Automation: W 61909-2RS1 Bearing
For robotic arms and automated systems, W 61909-2RS1 Bearing provides smooth rotation and low friction. The compact size and metric dimensions make it easy to integrate into various designs.

Medical vs Industrial: Where W 61909-2RS1 Bearing Excels
In medical devices like lab equipment, W 61909-2RS1 Bearing’s stainless steel material ensures hygiene and durability. Meanwhile, in industrial settings, it handles moderate loads with consistent performance.

Consumer Electronics and W 61909-2RS1 Bearing
You’ll find W 61909-2RS1 Bearing in household appliances like washing machines, where its sealed design protects against dust and moisture. The quiet operation also makes it ideal for noise-sensitive environments.
