Stainless Steel Deep Groove Ball Bearings W 61808-2RS1

Stainless Steel Deep Groove Ball Bearings W 61808-2RS1

The W 61808-2RS1 is a compact stainless steel deep groove ball bearing, measuring 40mm by 52mm by 7mm. It handles radial loads up to 877 lbf and spins smoothly at speeds up to 7500 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance and durable. The all-stainless construction resists corrosion, ideal for humid or wet environments.

This bearing is interchangeable with SKF models, offering a reliable replacement option. It works well in temperatures from -30°C to 120°C, suitable for food processing or marine applications.

Weighing just 0.032kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61808-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 877 lbf
  • Static Radial Load 843 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Weight 0.032 kg
Stainless Steel Deep Groove Ball Bearings W 61808-2RS1 dimension drawing
Download DWG Download PDF

Features

How Does W 61808-2RS1 Bearing Resist Wear?

W 61808-2RS1 Bearing is crafted entirely from stainless steel, offering excellent resistance to wear and corrosion.
Its sealed design keeps contaminants out, ensuring smooth operation in various environments.

The single-row construction provides reliable radial load support, with a dynamic load capacity of 877 lbf.
Grease lubrication enhances its performance, reducing friction and extending service life.

With a maximum speed of 7,500 rpm, W 61808-2RS1 Bearing balances durability and efficiency.
It operates smoothly in temperatures ranging from -30° to 120°C, making it versatile for different applications.

Application

Industrial Uses of W 61808-2RS1 Bearing
W 61808-2RS1 Bearing is commonly used in conveyor systems, where its sealed design protects against dust and debris. The stainless steel construction ensures longevity even in humid or corrosive environments.

Where Is W 61808-2RS1 Bearing Used?
In automotive applications, W 61808-2RS1 Bearing fits well in electric motors and small gearboxes. Its compact size and radial load capacity make it ideal for tight spaces.

Perfect Fit for Automation: W 61808-2RS1 Bearing
W 61808-2RS1 Bearing works smoothly in robotic arms, providing reliable rotation with minimal maintenance. The grease lubrication keeps it running quietly in continuous operations.

Medical vs Industrial: Where W 61808-2RS1 Bearing Excels
W 61808-2RS1 Bearing is suitable for medical devices like dental drills, offering precision and hygiene. In industrial settings, it handles moderate loads in packaging machinery.

Essential Roles of W 61808-2RS1 Bearing
For household appliances, W 61808-2RS1 Bearing ensures quiet performance in fans and small motors. The metric dimensions make it easy to replace in various European-made devices.
