Stainless Steel Deep Groove Ball Bearings W 6008-2RS1

Stainless Steel Deep Groove Ball Bearings W 6008-2RS1

The W 6008-2RS1 is a stainless steel deep groove ball bearing with a 40mm bore and 68mm outer diameter, measuring 15mm wide. Its sealed design keeps grease in and dirt out, making it low-maintenance.

This single-row bearing handles radial loads up to 3282 lbf and runs smoothly at speeds up to 6300 RPM. The all-stainless construction resists corrosion and lasts longer in tough conditions.

With standard P0 tolerance and CN clearance, it fits most applications needing reliable performance. Ideal for food processing equipment or marine use where rust resistance matters.

Weighing 0.18kg, it’s a sturdy yet lightweight choice. Compliant with RoHS and REACH standards for safe use across industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6008-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 68 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 3282 lbf
  • Static Radial Load 2563 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 0.18 kg
  • Price（$） 32.85
Stainless Steel Deep Groove Ball Bearings W 6008-2RS1 dimension drawing
Download DWG Download PDF

Features

How Does W 6008-2RS1 Bearing Reduce Friction?

W 6008-2RS1 Bearing features stainless steel construction, ensuring smooth operation with minimal friction.

Its sealed design keeps contaminants out, maintaining consistent performance over time.

The single-row deep groove design enhances radial load capacity, supporting up to 3282 lbf.

With a maximum speed of 6,300 rpm, it balances efficiency and durability in various applications.

Application

Industrial Uses of W 6008-2RS1 Bearing
W 6008-2RS1 Bearing is commonly used in industrial machinery like pumps and compressors, where its sealed design protects against contaminants. The stainless steel construction ensures durability in harsh environments, making it a reliable choice for long-term use.

In automotive applications, W 6008-2RS1 Bearing fits well in electric motors and alternators, providing smooth radial load support. Its metric dimensions and grease lubrication make it compatible with various vehicle systems.

For household appliances, W 6008-2RS1 Bearing works efficiently in washing machines and fans, offering quiet operation. The sealed design also helps prevent grease leakage, extending the bearing’s lifespan.

Automation and robotics benefit from W 6008-2RS1 Bearing’s precision and low maintenance needs. Its stainless steel components resist corrosion, ideal for cleanroom or high-humidity settings.

Medical devices like lab equipment often use W 6008-2RS1 Bearing for its consistent performance. The P0 tolerance class ensures reliable operation in sensitive applications.
